CD Automation REVO C 2PH 1100A User Manual page 36

REVO C
2PH from 1100A to 2100A
8.9.1 SSR Control Input schematic
For SSR input use follow the schematic below and configure Digital Input 1 as Fast Enable.
T1 T2
Delta
9
13
10
M5
SSR
INPUT
* SSR Input: 4÷30Vdc 5mA Max (ON >4Vdc / OFF <1Vdc)
Frequency 3Hz Max - On time min. 100 ms
Load Type
T3
T1 T2
Star
Analog Input 1
5
11
6 12
36
User's manual
T3
