9.4.3 Advanced Setup Menu
This section describes each item on the advanced setup menu. Use this menu to configure the power
switching, closed loop control of power and adjustable settings for data logging and heater bakeout. The
password to access this menu is 10.
Parameter Name
Firing Type
Choose the firing mode
Parameter Name
Min Cycles
Set the minimum number of On
cycles and off cycles for burst firing.
Start Ramp
Set the number of half cycles over
which the power ramps each time the
output turns on.
Delay
Set the firing delay degrees. Applies
to burst firing with delay trigger
Cycle time
Set the duration of one on-off cycle in
increments of 50mSec.
Applies to zero crossing
Feedback
Choose the feed-back type
Description
Option
Zero Cross
Burst fire
DEFAULT: Burst Fire
Description
Option
V²
Voltage squared
None
No feed-back
I²
Current squared
Voltage
Voltage
Current
Current
Power
Power
External
External signal via analog input 2
DEFAULT: None
