CD Automation REVO C 2PH 1100A User Manual page 16

REVO C
2PH from 1100A to 2100A
5.1.1 Order code
REVO C 2PH
CURRENT
description
1100A
1400A
1600A
1800A
2100A
MAX VOLTAGE
description
480V
600V
690V
AUX SUPPLY VOLTAGE
description
100/120Vac
200/208/230/240Vac
MAIN INPUT
description
SSR
0:20mA
4:20mA
0:10V
10KPot
FIRING
description
Burst Firing
Zero Crossing
CONTROL MODE
description
Open Loop
Voltage
Voltage Square
Current
Current Square
Power VxI
External feedback
1 2 3 4 5
R C 2 _ _
FUSES 4
description code
Fixed Fuses Included 1
Fixed Fuses Included 1
Fixed Fuses Included 1
Fixed Fuses Included 1
Fixed Fuses Included 2
code
AUX VOLTAGE RANGE
description code
90 to 135Vac
180 to 265Vac
code
START OPTION
description code
No Soft Start
No Soft Start
code
6 7 8
_ - _ _
5 6 OPTION
description
1 H No Option
4 H Option code - see table
6 H
8 H FAN VOLTAGE
1 H description
Fan 115Vac
7 Fan 230Vac Std Version
4
APPROVALS
6 description
7 CE EMC For European Market - IP protection rating = 0
CE EMC For European Market - IP protection rating = 20
8 UL + CE EMC For European Market - IP protection rating = 0
UL + CE EMC For European Market - IP protection rating = 20
1
2 LOAD TYPE
description
9 Normal Resistance
IRSW Infrared Short Wave
S
B COMMUNICATION AND RETRANSMISSION
A description
V
®
K N°1 Modbus RTU
10
®
N°2 Modbus RTU
B
Z
N°1 Profibus ® DP + N°1 Modbus
11
0 N°1 Profinet ® IO + N°1 Modbus
U
Q
®
I N°1 Modbus TCP + N°1 Modbus
A
W
X N°1 Ethernet IP + N°1 Modbus
16
User's manual
