DEMO MANUAL DC1198B-A

pArts list

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 2 CIN2, CIN3
3 1 CSS
4 2 CO3, CO4
5 2 CO5, CO6
6 1 L1
7 1 R5
8 1 R6
9 1 R7
10 2 RS1, RS2
11 1 U1
Additional Demo Board Circuit Components
1 0 CIN4, CIN5 (OPT)
2 0 C2, C4, C5, CP, CFF
(OPT)
3 0 CO1, CO2 (OPT)
4 0 CO7 (OPT)
5 0 CO8 (OPT)
6 2 D1, D2
7 1 R1
8 1 R2
9 1 R8
10 1 RS3 (OPT)
11 1 R9, RUVLO (OPT)
Hardware/Components (For Demo Board Only)
1 2 JP1, JP2
2 2 JP3, JP4
3 4 JP1, JP2, JP3, JP4
4 10 TP1, TP4, TP5, TP7,
TP9, TP11 TO TP15
5 4 TP2, TP3, TP8, TP10 BANANA JACK
6 4 STAND OFF
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP, ALUM, 150µF, 20%, 35V
CAP, X7R, 10µF, 20%, 35V, 1206
CAP, X7R, 0.01µF, 25V, 10%, 0603
CAP, X7R, 22µF, 16V, 20%, 1812
CAP, OS-CON, 180µF, 16V
IND IRON POWER SMT FIXED, 3.3µH
RES, CHIP, 7.15k, 1/16W, 1%, 0603
RES, CHIP, 4.64k, 1/16W, 1%, 0603
RES, CHIP, 1.21k, 1/16W, 1%, 0603
RES, CHIP, 0.015 1/2W, 1%, 1206
I.C., LTM4605EV#PBF
CAP, 1206
CAP, 0603
CAP, SVP, 100µF, D3L
CAP, 1206, 16V
POSCAP, D3L
ZENER DIODE, 4.7V
RES, CHIP, 100k, 1/16W, 5%, 0603
RES, CHIP, 51k, 1/16W, 5%, 0603
RES, CHIP, 20k, 1/16W, 1%, 0603
RES,1206
RES, 0603
2mm SINGLE ROW HEADER, 3 PIN
2mm SINGLE ROW HEADER, 4 PIN
SHUNT
TESTPOINT, TURRET, 0.095"
STAND OFF, NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
SANYO, 35ME150WXV+TS (NOW SUNCON 35ME150WXV)
TAIYO YUDEN, GMK316BJ106ML-T
AVX 06033C103KAT4A
TDK C4532X7R1C226M
SANYO 16SVP180MX
TOKO FD1254-3R3M=P3
VISHAY CRCW06037K15FKEA
VISHAY CRCW06034K64FKEA
VISHAY CRCW06031K21FKEA
VISHAY WSL1206R0150FEA
LINEAR TECHNOLOGY CORPORATION LTM4605EV#PBF
CENTRAL SEMICONDUCTOR CMDZ5230B-7-F
VISHAY CRCW0603100KJNEA
VISHAY CRCW060351K0JNEA
VISHAY CRCW060320K0FKEA
SAMTEC TMM-103-02-L-S
SAMTEC TMM-104-02-L-S
SAMTEC 2SN-BK-G
MILL-MAX 2501-2-00-80-00-00-07-0
KEYSTONE 575-4
KEYSTONE 8833 (SNAP ON)
