3. Setting Up the DMS 2
Step 3: Each grid type is shown in the display screen's A-
scan window as that type is selected with
Step 4: The A-scan grid style will be the choice last dis-
played.
Setting the Display Backlighting (DISP-BacKLITE)
The BACKLITE feature increases the display's brightness to
allow for improved visibility in low-light situations.
Step 1: Activate the DISPLAY Submenu (if it's not already
activated) by selecting it with
lighted. Five selections will appear across the bottom of the
display screen.
Step 2: Press
below the selection titled BKLITE. You'll
note that the following choices are available:
• ON—Backlight remains on continuously.
Page 50
.
or so that it's high-
• OFF—Backlight remains off.
• AUTO—Backlight illuminates when the probe is coupled
then automatically turns off five seconds after uncoupling.
Step 3: The backlight mode will be set to the choice last dis-
played.
3.2.2

Global Settings

Use the procedures below to adjust global (system-wide)
parameters. These parameters include the language that
appears on the instrument's display screens and data
output, the format of the date and time, and the actual date
and time. The adjustments will require access to the GLO-
BAL submenu. This is accessed from the TG Secondary
Menu (shown in Figure 3-3).
Setting the Operating Language (GLOBAL-LANG)
Step 1: Activate the GLOBAL Submenu (located in the TG
Secondary Menu) by selecting it with
highlighted. Five selections will appear across the bottom of
the display screen.
or so that it's
