Step 5: The DR display option will be set to the last option
selected.
NOTE: Regardless of the instrument settings, all micro-
grids will be displayed in SPREAD VIEW.
5.2.7

Storing and Recalling A-scans

Attaching A-scans to Data Points —The SEND Button's
Test-Mode Function
Pressing normally results in a thickness measure-
ment being stored in the active file position. It is also pos-
sible to store an A-scan in the active file position, together
with the thickness measurement, by adjusting the value of
the SEND FUNCTION feature located in the RECORD
Submenu. (Note that there are additional send functions,
related to communication with external-devices, which can
be selected as explained in Chapter 6.)
Step 1: Open the Data Recorder by pushing
Step 2: Make sure that the data file you wish to work with is
open.
DMS 2 Operating Manual
Step 3: Activate the RECORD Submenu by selecting it with
or
across the bottom of the display screen including ITEM and
VALUE.
Step 4: Press
note that several file characteristics are listed including
SEND FUNCTION.
Step 5: Press
SEND FUNCTION is highlighted.
Step 6: Press
options are available:
THICKNESS ONLY – sends only the thickness reading to the
.
file position when
THCK / THCK+ASCAN – sends the thickness reading and
A-scan to the file position when
5. Working with Stored Data
so that it's highlighted. Selections will appear
below the selection titled ITEM. You'll
below the selection titled ITEM until
below the selection titled VALUE. Two
is pressed.
is pressed and held
Page 155
