DATA RECORDER MENU
RECORD Submenu
• FILE—Scrolls through a list of all stored data
files. Automatically opens files while
scrolling. (Refer to Section 5.1.1)
• ITEM—Scrolls through a list of all items
(related to file type and size) in the selected
file. (Refer to Sections 5.2.3 and 5.3.3)
• VALUE—Displays the value inputted for the
file feature selected in ITEM. (Refer to
Sections 5.2.3 and 5.3.3)
• QUIT SEARCH—Only visible when the
search mode is active. (Refer to Section
5.2.4)
• VIEW—Adjusts how data is displayed in the
DR navigation window (Spread or List View).
(Refer to Section 5.2.6)
STATS Submenu
• FILE—Scrolls through a list of all stored data
files. Automatically opens files while
scrolling. (Refer to Section 5.1.1.)
• STAT—Scrolls through the stats list to allow
tagging. (Refer to Section 5.2.4.)
DMS 2 Operating Manual
2. Understanding the DMS 2 Keyboard, Menu Systems, and Displays
• TAG—Attaches a "tag" to the parameter
selected in STAT. This allows the item to be
located with a SEARCH. (Refer to Section
5.2.4)
• SEARCH—Allows the user to search
through the active data file and identify
measurements that contain the tagged
features. (Refer to Section 5.2.4.)
HEADER Submenu
• FILE—Scrolls through a list of all stored data
files. Automatically opens files while
scrolling. (Refer to Section 5.1.1)
• ITEM—Scrolls through a list of all items
(related to file type and size) in the selected
file. (Refer to Section 5.3.2)
• VALUE—Displays the value inputted for the
file feature selected in ITEM. (Refer to
Section 5.3.2)
• FILE DELETE—Gives the user the ability to
delete the active file or all files. (Refer to
Section 5.1.4)
MEMORY Submenu
• FILE—Scrolls through a list of all stored data
files. Automatically opens files while
scrolling. (Refer to Section 5.1.1.)
• REPORT—Specifies the type of report to be
generated when the PRINT command is
activated. (Refer to Section 6.3.1)
• PRINT—Causes the report type specified in
REPORT to be generated and sent to the
I/O port. (Refer to Section 6.3.2)
EDIT Submenu
• ITEM—Scrolls through a list of all items
(related to file type and size) in the
selected file. (Refer to Section 4.3.3.)
• MODE—Indicates a file will be modified by
inserting, appending, or deleting thickness-
measurement locations. (Refer to Section
4.3.3.)
• AT—Active in insert and delete mode.
• APPEND/INSERT/DELETE—Adds or
removes measurement locations to or from a
data file. (Refer to Section 4.3.3.)
