4. Measuring Thickness
Step 3: Press below the selection titled A-WDTH. You'll
note that the width of the A-gate shown on the A-scan display
screen will increase or decrease (Figure 4-14).
Step 4: The A-gate width will remain as specified until it's
manually adjusted.
Adjusting the A-gate Height or Threshold (A-GATE–A-THR)
The height or threshold level of the A-gate is adjustable. This
may be necessary in multi-echo modes because the returning
sound pulse (backwall echo) may be too low in amplitude to
trigger a measurement reading. Use the following procedure to
adjust A-THR.
Step 1: Activate the TG Primary Menu (if it's not already
active) by pressing .
Step 2: Activate the A-gate Submenu (located in the TG
Primary Menu) by selecting it with
highlighted. Five selections will appear across the bottom of the
display screen.
Page 122
or so that it's
Step 3: Press below the selection titled A-THR. You'll
note that the height of the A-gate shown on the A-scan
display screen will move up or down (Figure 4-14).
Step 4: The A-gate height will remain where it's positioned
until it's manually adjusted.
Adjusting the B-gate Starting Point (B-GATE–B-STRT)
B-STRT adjusts the starting point of the B-gate. Use the
following procedure to adjust B-STRT.
Step 1: Activate the TG Primary Menu (if it's not already
active) by pressing .
Step 2: Activate the B-gate Submenu (located in the TG
Primary Menu) by selecting it with
highlighted. Four selections will appear across the bottom of
the display screen.
or so that it's
