DR MODE DISPLAY
• Available Data Files — An alphabetical list of all stored
data files appears in this window whenever the instrument
is in the DR Mode. Selecting data files, by pressing
below the FILE selection box, activates each file as it's
highlighted. NO ACTIVE FILE is an available option. When
NO ACTIVE FILE is selected, TG Mode shows "BIG
DIGITS MODE" ¾" thickness digits. (Refer to Section 5.1)
• ITEMS—Features within a File that relate to the Selected
Data Point or the way in which the File is formatted.
• VALUES—The quantity or characteristic assigned to each
ITEM. Many values can be adjusted from the RECORD
and HEADER Submenus.
DMS 2 Operating Manual
2. Understanding the DMS 2 Keyboard, Menu Systems, and Displays
• Selected File Position—The position where the next data
point will be sent when
changed when operating in the File Navigation Mode. File
Nav is accessed by pressing
Section 5.2.)
• Battery Life Indicator—Shows the remaining battery
life with reduced black shading in the icon. (Refer to
Section 3.1.)
• Rectification—Allows advanced users to adjust the way
in which the A-scan is displayed. (Refer to Section 4.6.)
is pressed. This location is
, then using
to move within the file's data points. (Refer to
or
Page 37
