Two bars — good signal strength.
One bar — low signal strength, stable operation is not guaranteed.
Crossed out icon — no signal.
The signal strength is in uenced by the following factors: the number of devices
connected to one bus, the length and type of cable, and the proper connection of
the wires to terminals.
Check the Fibra signal strength before nal installation of the detector. With a signal
strength of one or zero bars, we do not guarantee stable operation of the device.
The maximum permissible cable length depends on its type, its material, and the
method of connecting the devices. When connected via the beam connection
using the U/UTP cat.5 (4×2×0.51) twisted pair, the wired connection length can
reach up to 2,000 meters.
When devices are connected via the ring connection method, the maximum
cable length is 500 meters in case of using a twisted pair.
How to calculate the wire connection length (in progress)
Connecting devices using the ring connection method will be available with future OS
Malevich updates. Hardware update of Hub Hybrid won't be required.
How OS Malevich updates

Detection zone

When choosing where to place the detector, perform the
check the operation of the device and accurately determine the sector in which
the detector registers motion.
The location of the detector determines the area to be monitored and the
effectiveness of the security system. When choosing the installation location,
Detection zone test to
