AJAX MotionProtect Plus Fibra User Manual page 10

Before installing MotionProtect Plus Fibra, make sure that you have selected the optimal
location and that it meets the conditions of this manual. Cables must be hidden from
view and located in a place that is di cult for intruders to access to reduce the
likelihood of sabotage.
Ideally, mount them in the walls, oor, or ceiling. Before the nal installation, conduct
tests of the detection zone
When connecting to the detector terminals, do not twist the wires together;
solder them. The ends of the wires that will be inserted into the terminals should
be tinned or crimped with special tips. This will ensure a reliable connection.
Follow safety procedures and regulations for electrical installation work.
In order to mount a detector:
1. Disconnect the hub external power supply and the backup battery.
1 — External power supply
2 — Backup battery
2. Plug the cable into the hub and connect the wires to the bus terminals.
and the Fibra signal strength.
