Analog Devices ADSP-BF561 EZ-KIT Lite Manual page 85

A
SW11
1 8
VIDEO_AVIN1
2 7
VIDEO_AVIN4
3 6
VIDEO_AVIN5
4 5
SWT018
DIP4
SW11: Video Loopback
For Test Purposes
1
Default = All Off
VIDEO ENCODER
2
U8
PPI1_D7 5
PPI1_D[15:0] P7
PPI1_D6 4
P6
PPI1_D5 3
P5
PPI1_D4 39
P4
PPI1_D3 38
P3
PPI1_D2 37
P2
PPI1_D1 36
P1
PPI1_D0 35
P0
1
VENC_27MHZ_CLK CLOCK
20
VENC_RESET RESET
16
ALSB
3
PF1 22
PF[15:0] SDATA
PF0 21
SCLOCK
3V_B
32
SCRESET/RTC
R13
100K 34
TTX
1206
33
TTXREQ
ADV7179
LFCSP40
R143 R9
10K 100K
805 1206
4
A
B
VIDEO_DAC_A
VIDEO_DAC_C
VIDEO_DAC_B
3V_B
2
VAA1
10
VAA2
18
VAA3
R14 C115 C12 R23
25 10K 0.1UF 0.1UF 1.2K
VAA4
805 805 805 1206
27
VAA5
29
DAC_A
28
DAC_B
24
DAC_C
23
COMP
30
VREF
31
RSET
13
HSYNC VENC_HS
14
FIELD/VSYNC VENC_VS
15
BLANK
6
GND1
7
GND2
8
GND3
1
9
D1
GND4
R3
AD1580
11 150
SOT23D
GND5
1206
2
12
GND6
17
GND7
19
GND8
26
GND9
40
GND10
R133
0.00
1206
AGND2
B
C
R136
1K
1206
A3V
U3
4 5
L1 L5 L4
0.68UH 2.2UH 0.68UH
805 805 805
3 AD8061ART
SOT23-5
2
R10
R114 C92 C86 R6 1K
75 330PF 330PF 75 1206
1206 805 805 1206
AGND2
R116
1K
1206
A3V
U1
4 5
L8 L9 L2
0.68UH 2.2UH 0.68UH
805 805 805
3 AD8061ART
2 SOT23-5
R115
R135 C94 C82 R4 1K
75 330PF 330PF 75 1206
1206 805 805 1206
AGND2
R118
1K
1206
A3V
U2
4 5
L6 L7 L3
0.68UH 2.2UH 0.68UH
805 805 805
3 AD8061ART
SOT23-5
2
R117
R134 C93 C84 R5 1K
75 330PF 330PF 75 1206
1206 805 805 1206
AGND2
Approvals
Drawn
Checked
Engineering
C
VIDEO_DAC_A
J6
R104 3X2
75 CON024
1206
1 8 DAC A
9
VIDEO_DAC_B
J6
R107 3X2
75 CON024
1206 DAC B
1 5
6
VIDEO_DAC_C
J6
R105 3X2
75 CON024
1206
1 2 DAC C
3
ANALOG
DEVICES
Title
Date
ADSP-BF561 EZ-KIT LITE:
JSZ 10/10/03
Size Board No.
A0185-2003
C
Date 5-12-2004_16:35
D
1
DAC A DAC B DAC C
Composite Video CVSB CVSB C
Component Video G B R
Differential Component Video Y U V
S Video Y C
2
3
20 Cotton Road
Nashua, NH 03063
4
PH: 1-800-ANALOGD
VIDEO ENCODER (VIDEO OUT)
Rev
1.3A
Sheet 9 of 18
