• Analog Audio Interface
AD1836 A – Analog Devices 96 kHz audio codec
4 input RCA phono jacks (2 Stereo Channels)
6 output RCA phono jacks (3 Stereo Channels)
• Analog Video Interface
ADV7183A video decoder w/ 3 input RCA phono jacks
ADV7179 video encoder w/ 3 output RCA phono jacks
• Universal Asynchronous Receiver/Transmitter (UART)
ADM3202 RS-232 line driver/receiver
DB9 male connector
• LEDs
20 LEDs: 1 power (green), 1 board reset (red), 1 USB (red),
16 general purpose (amber), and 1 USB monitor (amber)
• Push Buttons
5 push buttons with debounce logic: 1 reset,
4 programmable flags
• Expansion Interface
PPI0
Programmable Flags,
• Other Features
JTAG ICE 14-pin header
The EZ-KIT Lite board holds 8 MB of flash memory, which can be used
to store user-specific boot code, allowing the board to run as a stand-alone
unit. The board also holds 512-Mb SDRAM, which can be used at runt-
ime. For more information see
ADSP-BF561 EZ-KIT Lite Evaluation System Manual
, , , ,
PPI1 SPI EBIU
SPORT0
"External Memory" on page
, ,
Timers11-0 UART
,
SPORT1
Preface
1-6.
