NOTE

USB Connector

The USB interface consists of an USB type B connector that connects directly to the
provided USB cable.

Debug Port Connector

The debug connector consists of a 5.5 inch ribbon cable with the appropriate debug
connector attached. The ribbon cable has a red stripe down one side to indicate the
location of pin 1.
NOTE
Ethernet Tap Users Guide
When the USB TAP is powered on, it performs a brief self-test that
displays a test pattern on both LEDs. After the self-test completes, it
reverts to the behavior described above.
The OnCE connector is equipped with a removable plug in pin 8.
This follows the keying convention for the OnCE header (pin 8
should be removed). This plug is removable, in case the target being
connected to it does not come with pin 8 removed.
Hardware Specifications
Connectors and LEDs
23
