Hardware Specifications
This chapter provides hardware specifications for the USB TAP emulator.
The sections are:
•
Connectors and LEDs
•
USB TAP Specifications
Connectors and LEDs
Figure 4.1
device.
Figure 4.1 USB TAP Device—Top View
Transmit/Receive LED
Run/Pause LED
USB TAP Users Guide
and
Figure 4.2
show the various LEDs and connectors of the USB TAP
Debug port connector
4
21
