4.2. Installing Optional SIM Card
The SIM card provides telephony communication for data transfer between two GSM-capable receivers.
The SIM card can be purchased at your local cellular phone supply store. Once installed, the card
generally remains installed.
The SIM card must support Circuit Switched Data to communicate directly between receivers. The SIM
card must have GPRS support to communicate with a GPS Network IP address.
To install SIM card:
1. Ensure the receiver is turned off.
2. Open the bottom of the case screwing off 9 self taping screws (Figure 3).
3. Remove battery and open SIM holder.
4. Carefully insert the SIM into the SIM card holder and push it to LOCK to close it tightly.
16
Screw
Figure 3. SIM Card installation
2
Figure 4. SIM Card installation 2
SIM card Holder
Battery
1
