IMB760 LGA4189 EATX Motherboard
2.5.4 10GbE LAN port (LAN1 & 2)
The IMB760 comes with two 10GbE LAN ports. The pin assignments are listed on the
following table.
Pin
J1
J2
J3
J4
J5
J6
J7
J8
Left LED
Right LED
2.5.5

GPIO Header (CN5)

This header (5x2-pin p=2.00mm) is for digital I/O interface.
Pin Signal
1 DIO1
3 DIO2
5 DIO3
7 DIO4
9 NC
The default value of DIO1 to DIO8 is set as GPI with high level.
Note
2.5.6

TPM Pin Header (CN11)

The header (7x2-pin p=2.0mm) is for SPI interface with an AX93515 TPM module.
Pin Signal
1 VCC3P3
3 MOSI
5 CLK
7 RST
9 PP
11 NC
13 NC
The screw type is M2*0.4.
Note
12
Description
MDI0+
MDI0-
MDI1+
MDI2+
MDI2-
MDI1-
MDI3+
MDI3-
Speed LED：
10G (Green)
1G (Orange)
100M (No light)
Active LED (Green)
Pin Signal
2 DIO8
4 DIO7
6 DIO6
8 DIO5
10 GND
Pin Signal
2 GND
4 MISO
6 CS2
8 PIRQ
10 NC
12 NC
14 MC
13 11 9 7 5 3 1
14 12 10 8 6 4 2
Board and Pin Assignments
