The TPM 2.0 (Trusted Platform Module 2.0) module features a modularized design compatible
with the IMB760 and provides enhanced hardware security for the computer. In this appendix
you will learn how to install the TPM 2.0 module into the IMB760. Please read and follow the
instructions below carefully.
Insert TPM module into the SPI interface of the motherboard, as illustrated below.
1.
AX93515 TPM
module
There are two ways to confirm whether the TPM Module is installed successfully or not:
2.
a. Enter the BIOS setup menu and go to Trusted Computing. The first line will show
"TPM2.0 Device Found".
TPM Module Installation
TPM Module Installation
TPM SPI interface
(In the Advance menu, go to Trusted Computing)
IMB760 LGA4189 EATX Motherboard
Appendix B
TPM module put in place
59
