AXIOMTEK IMB200 User Manual

Intel pentiumd/pentium4/celeron d industrial atx motherboard
Hide thumbs Also See for IMB200:
Table of Contents

Advertisement

Quick Links

Download this manual
IMB200
®
Intel
PentiumD/Pentium4/Celeron D
Industrial ATX Motherboard
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMB200 and is the answer not in the manual?

Questions and answers

Related Manuals for AXIOMTEK IMB200

Summary of Contents for AXIOMTEK IMB200

  • Page 1 IMB200 ® Intel PentiumD/Pentium4/Celeron D Industrial ATX Motherboard User’s Manual...

  • Page 2: Disclaimers

    Disclaimers The information in this manual has been carefully checked and is believed to be accurate. AXIOMTEK Co., Ltd. assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. AXIOMTEK assumes no responsibility for any inaccuracies that may be contained in this document.

  • Page 3: Esd Precautions

    Wear a wrist-grounding strap, available from most electronic component stores, when handling boards and components. Trademarks Acknowledgments AXIOMTEK is a trademark of AXIOMTEK Co., Ltd. IBM is a registered trademark of International Business Machines Corporation. MS-DOS, and Windows 2000 are trademarks of Microsoft Corporation.

  • Page 4: Table Of Contents

    T a b l e o f C o n t e n t s Disclaimers ..............ii ESD Precautions ............iii Chapter 1 Introduction............1 General Description ..........1 Specifications ............2 Utilities Supported..........3 Ordering information ..........3 Board Dimensions ..........
  • Page 5 4.13 Serial ATA Connectors-CN28/CN29 ...... 29 4.14 PS/2 Keyboard/Mouse connector-CN4 ....29 4.15 Digital I/O Connector-CN38 ........30 4.16 CD/IN Connector-CN9 .......... 30 4.17 CPU/System FAN Connector-CN23/CN24 ..... 31 Chapter 5 Installing VGA driver ......... 32 Introduction............32 Driver Disks’ Contents........32 Windows 2000 VGA Driver Installation ....
  • Page 6 AppendixC Detailed memory Addess Mapping ....70 AppendixD I/O Shield............71...

  • Page 7: Chapter 1 Introduction

    IMB200 LGA775 ATX MB User Manual Chapter 1 Introduction General Description The IMB200 supports LGA775-pin Intel® Pentium® D (Intel Dual-Core) processor up to 3.6GHz with a 533/800MHz front side bus (FSB), and features an Intel® 865G + ICH*5 chipset. With Intel dual-core processing technology, the...

  • Page 8: Specifications

    IMB200 LGA775 ATX MB User Manual Specifications ® Processor: Intel Pentium D/Pentium4/Celeron ® North Bridge: Intel 82865G ® South Bridge: Intel 82801EB(ICH5) CPU Socket: LGA775 FSB: 533/800 Mhz L2 Cache: Integrated in CPU(Depend on CPU) BIOS: Phoenix Award BIOS Rev.6.00...

  • Page 9: Utilities Supported

    IMB200 LGA775 ATX MB User Manual CF Socket: Support CF Type II Socket USB Interface: 4 USB ports; USB Spec. Rev. 2.0 compliant. Hardware Monitoring: Winbond W83627HG-AW detection of CPU temperature, System temperature, Power failure and Fan speed. Watchdog Timer:...
  • Page 10 IMB200 LGA775 ATX MB User Manual Introduction...

  • Page 11: Board Dimensions

    IMB200 LGA775 ATX MB User Manual Board Dimensions Introduction...

  • Page 12: Chapter 2 Jumpers And Connectors

    IMB200 LGA775 ATX MB User Manual Chapter 2 Jumpers and Connectors Board Layout Jumpers and Connectors...

  • Page 13: Jumper Settings

    IMB200 LGA775 ATX MB User Manual Jumper Settings Followed as below detailed description for Jumper setting and installed the IMB200 for your application Jumper Setting Jumper Default Setting Watchdog Trigger Mode : OPEN Disable Short 1-2 for NMI Short 2-3 for Reset...

  • Page 14: Clear Cmos Setting: Jp7

    IMB200 LGA775 ATX MB User Manual 2.2.2 Clear CMOS Setting: JP7 Options Settings Normal 1-2(Default) Clear CMOS 2.2.3 CF Master/Slave Setting: JP8 Options Settings Master Short(Default) Slave Open Jumpers and Connectors...

  • Page 15: Cf Power Setting: Jp9

    IMB200 LGA775 ATX MB User Manual 2.2.4 CF Power Setting: JP9 Options Settings 3.3V 1-2(Default) Jumpers and Connectors...

  • Page 16: Connectors

    IMB200 LGA775 ATX MB User Manual 2.3 Connectors The following table lists the function of each connector on IMB200. Connectors Label Connectors Label General Output CN37 Primary IDE IDE1 Connector Connector Printer Port Connector Secondary IDE IDE2 Connector COM1 Compact Flash...
  • Page 17 IMB200 LGA775 ATX MB User Manual Connectors Label Connectors Label ATX Power Connector CN31 PCI Slot PCI1~ LGA775 CPU Socket AGP Slot AGP8 DIO Connector CN38 Jumpers and Connectors...

  • Page 18: Chapter 3 Installation

    IMB200 LGA775 ATX MB User Manual Chapter 3 Installation Before installing the processor, Please pay more attention on Intel website and obtained more information http://www.intel.com. 3.1 CPU Installation The LGA775 processor socket comes with a lever to protect the processor. Please pay more attention as below. Follow the pictures and place the processor into CPU socket.
  • Page 19 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 20 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 21 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 22 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 23 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 24 IMB200 LGA775 ATX MB User Manual Installation...

  • Page 25: Installing Atx Power Supply

    Dual Channel DDR 266/333/400 memory and support the maximum memory capacity could up to 4GB. If you want to know what is difference between DDR and DDR2.See below picture PS: IMB200 only support Un-Buffered DIMM and could not support ECC/Registered DIMM Installation...
  • Page 26 IMB200 LGA775 ATX MB User Manual Installation...

  • Page 27: Chapter 4 Hardware Description

    IMB200 LGA775 ATX MB User Manual Chapter 4 Hardware Description 4.1 General Output Connector: CN37 Power LED Pins 1, 3, 5, 7 connect the system power LED indicator to its respective switch on the case. Pin 1 is +, and pin 5 is assigned as -.Pin 7 is defined as NC...

  • Page 28: Display Interface-Cn1

    IMB200 LGA775 ATX MB User Manual Description Description Description Reset # Data 7 Data 8 Data 6 Data 9 Data 5 Data 10 Data 4 Data 11 Data 3 Data 12 Data 2 Data 13 Data 1 Data 14 Data 0...

  • Page 29: Floppy Disck Connector-Fdd

    IMB200 LGA775 ATX MB User Manual 2048x1536 at 75 Hz. Signal Pin Signal Pin Signal Green Blue AGND AGND AGND 11 N/A 12 DDC DAT Horizontal 14 Vertical 15 DDC CLK Sync Sync 4.4 Floppy Disk Connector-FDD IMB200 provides a 34-pin header type connector supporting up to two floppy drives.

  • Page 30: Parallel Port Connector

    IMB200 LGA775 ATX MB User Manual Motor enable B # Direction # STEP # Write data # Write gate # Track # Write protect # Read data # Side 1 select # Disk change # 4.5 Parallel Port Connector Standard mode:...

  • Page 31: Com1 Port Connector-Cn2

    IMB200 LGA775 ATX MB User Manual Data 3 Data 4 Data 5 Data 6 Data 7 Acknowledge # Busy Paper Empty # Printer Select 4.6 COM1 Port Connector-CN2 4.7 COM2/3/4 Port Connector- CN25/CN27/CN33 support RS232 Hardware Description...

  • Page 32: Usb And Giagbit Lan Rj-45 Connector-Cn6

    IMB200 LGA775 ATX MB User Manual 4.8 USB and Gigabit LAN RJ-45 Connector- 4.9 USB and 10/100Mb LAN RJ-45 Connector-CN7 Hardware Description...

  • Page 33: Usb Connector By Pin Header-Cn30

    IMB200 LGA775 ATX MB User Manual .10 USB Connector by pin header-CN30 U SB G ND Power AG ND U SB Power G ND Hardware Description...

  • Page 34: Audio Jack (Line-In/Line-Out/Mic)-Cn3

    IMB200 LGA775 ATX MB User Manual 4.11 Audio Jack (Line-in/Line-Out/MIC)-CN3 4.12 ATX12V CPU Power Connector: CN14 This connector connected to an ATX12V power supply and used for CPU Core Voltage. Important Note: Make sure your ATX12V power supply can provide 16A on the +12V lead and at least 1A on the +5V standby lead (+5VSB).

  • Page 35: Serial Ata Connectors-Cn28/Cn29

    IMB200 LGA775 ATX MB User Manual 4.13 Serial ATA Connectors-CN28/CN29 4.14 PS/2 Keyboard/Mouse connector-CN4 Hardware Description...

  • Page 36: Digital I/O Connector-Cn38

    IMB200 LGA775 ATX MB User Manual 4.15 Digital I/O Connector-CN38 4.16 CD/IN Connector-CN9 Hardware Description...

  • Page 37: Cpu/System Fan Connector-Cn23/Cn24

    IMB200 LGA775 ATX MB User Manual 4.17 CPU/System FAN Connector- CN23/CN24 Hardware Description...

  • Page 38: Chapter 5 Installing Vga Driver

    IMB200 LGA775 ATX MB User Manual Chapter 5 Installing VGA driver Introduction The GMCH provides interfaces to a progressive scan analog monitor. The GMCH has an integrated 350 MHz RAMDAC that can directly drive a progressive scan analog monitor up to a resolution of 2048x1536 at 75 Hz.
  • Page 39 IMB200 LGA775 ATX MB User Manual To install or upgrade the Intel 865G video driver: Run SETUP.EXE from the driver directory on your drivers Follow the onscreen directions to complete installation. There may be messages about the driver not having a digital signature, select Yes to all these message boxes.

  • Page 40: Windows Xp Vga Driver Installation

    IMB200 LGA775 ATX MB User Manual Windows XP VGA Driver Installation To install video support If you have installed retail Windows you need to install the video driver. The driver is contained in the \IMB200\Drivers\VGA subdirectory on the drivers CD.

  • Page 41: Chapter 6 Installing Lan Driver

    IMB200 LGA775 ATX MB User Manual Chapter 6 Installing LAN Driver Introduction IMB200 was built-in high performance Plug and Play Ethernet interface which is fully compliant with the IEEE 802.3 standard, and consisting of the RJ-45 connector Features 10/100/1000BASE-T Triple-speed MAC...

  • Page 42: Chapter 7 Award Bios Utility

    IMB200 LGA775 ATX MB User Manual Chapter 7 Award BIOS Utility Please pay more time and check all of detailed information for BIOS settings when you want to used the IMB200 BIOS Introduction The Award BIOS (Basic Input/Output System) installed in your computer system’s ROM supports Intel Celeron processors in...
  • Page 43 IMB200 LGA775 ATX MB User Manual from various setup functions and exit choices. The section below the setup items of the Main Menu displays the control keys for this menu. Another section located at the bottom of the Main Menu, just below the control keys section, displays information on the currently highlighted item in the list.

  • Page 44: Standard Cmos Setup

    IMB200 LGA775 ATX MB User Manual Standard CMOS Setup “Standard CMOS Setup” allows you to record some basic hardware configurations in your computer system and set the system clock and error handling. If the motherboard is already installed in a working system, you will not need to select this option.
  • Page 45 IMB200 LGA775 ATX MB User Manual Date The date format is <day>, <month>, <date>, <year>. Press <F3> to show the calendar. The day of week, from Sun to Sat, determined by the BIOS, is read only The date, from 1 to 31 (or the maximum allowed in...
  • Page 46 IMB200 LGA775 ATX MB User Manual Drive A type/Drive B type The category identifies the types of floppy disk drive A or drive B installed in the computer. None No floppy drive installed 360K, 5.25 in 5.25 inch PC-type standard drive; 360Kb capacity 1.2M, 5.25 in...

  • Page 47: Advanced Bios Features

    IMB200 LGA775 ATX MB User Manual Advanced BIOS Features This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 7.4.1 CPU Feature Clicks the cursor to this field and press <Enter>. The following screen will be appeared.
  • Page 48 IMB200 LGA775 ATX MB User Manual may not be identical to this one. Delay prior to Thermal This filed is used to select the time that would force the CPU to a 50% duty cycle when it exceeds us maximum...

  • Page 49: Hard Disk Boot Priority

    IMB200 LGA775 ATX MB User Manual 7.4.2 Hard Disk Boot Priority This field is used to select the boot sequence of the hard drives. Move the cursor to this field then press <Enter>. Use the Up or Down arrow keys to select a device then press<+>...
  • Page 50 IMB200 LGA775 ATX MB User Manual Most people enable this setting to speed up the boot process, but you should realize that you do increase the chance of the POST missing an error if you use this. Fortunately (or unfortunately) the POST memory test is virtually useless to...
  • Page 51 IMB200 LGA775 ATX MB User Manual Boot Up NumLock Status This option enables and disables the numberlock function of the keypad. The default value is “On”. Keypad functions confine with numbers Keypad functions convert to special functions (i.e., left/right arrow keys)

  • Page 52: Advanced Chipset Features

    IMB200 LGA775 ATX MB User Manual Advanced Chipset Features Since the features in this section are related to the chipset on the CPU board and are completely optimized, you are not recommended to change the default settings in this setup table unless you are well oriented with the chipset features.
  • Page 53 IMB200 LGA775 ATX MB User Manual Manual If you want better performance for your system other than the one “ by SPD “ select “ Manual “ then select the best option in the “ CAS Latency Time “ To “System Memory Frequency “fields.
  • Page 54 IMB200 LGA775 ATX MB User Manual cache will allow access to video BIOS addressed at C0000H To be cached if the cache controller is also enabled. The larger the range of the Cache RAM, the faster the video performance. Memory Hole At 15M-16M You can reserve this area of system memory for ISA adapter ROM.
  • Page 55 IMB200 LGA775 ATX MB User Manual But if you are using multiple graphics cards, it is up to you which card you want to use as your primary display card. It is recommended that you select the fastest graphics card as the primary display card.

  • Page 56: Integrated Peripherals

    IMB200 LGA775 ATX MB User Manual Integrated Peripherals This option sets your hard disk configuration, mode and port. 7.6.1 On-Chip IDE Device Move the cursor to this field and press <Enter>. The following screen will be appeared. Award BIOS Utility...
  • Page 57 IMB200 LGA775 ATX MB User Manual On-Chip Primary PCI IDE This option could allow you to enable or disable the primary and secondary IDE controller, select Disabled if you want to add a Different hard drive controller. IDE Primary Master PIO...

  • Page 58: Onboard Device

    IMB200 LGA775 ATX MB User Manual This option could allow you to set up Master IDE interface from PIO mode0 to PIO Mode 4 IDE Primary Slave PIO This option could allow you to set up Slave IDE interface from PIO mode 0 to PIO Mode 4...
  • Page 59 IMB200 LGA775 ATX MB User Manual USB Controller This setting could help you enabled or Disabled Onboard USB controller USB 2.0 Controller Select enabled if your system contains a Universal Serial Bus V2.0 (USB2.0) controller and you have USB2.0 peripherals. The choice: Enabled, Disabled.

  • Page 60: Super Io Device

    IMB200 LGA775 ATX MB User Manual Select Disabled could help to disable onboard Gigabit Ethernet controller. 7.6.3 Super IO Device Move the cursor to this field and press < Enter >. The following Screen will be appeared. Onboard FDC Controller...
  • Page 61 IMB200 LGA775 ATX MB User Manual The choice: Half, Full. UR2 Duplex Mode Half: Data is completely transmitted before receiving Data Full: Transmits and receives data simultaneously. Onboard Parallel Port 378/IRQ7, 3BC/IRQ7, 278/IRQ5 Select the I/O address and IRQ for the onboard parallel port.

  • Page 62: Spread Spectrum

    IMB200 LGA775 ATX MB User Manual 7.6.5 Onboard UART 3/4 IRQ Use these BIOS setting could help to set up the IRQ for Onboard UART 7.6.6 Spread Spectrum Spread spectrum is a form of wireless communications in which the frequency of the transmitted signal is deliberately varied.

  • Page 63: Power Management Setup

    IMB200 LGA775 ATX MB User Manual Power Management Setup The Power Management Setup allows you to save energy of your system effectively. It will shut down the hard disk and turn OFF video display after a period of inactivity. ACPI Function This function should be enabled only in operating systems that support ACPI.
  • Page 64 IMB200 LGA775 ATX MB User Manual Saving: Minimum power saving time for the Suspend Mode (1 hour) and HDD Power Down (15 min.) Max Saving: Maximum power saving time for the Suspend Mode and HDD Power Down =1 min. User Define: Allows you to set the power saving time in The “Suspend Mode “and “HDD Power Down “fields.
  • Page 65 IMB200 LGA775 ATX MB User Manual Soft-Off by PWR-BTTN Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off state when the system has “hung.” The choice: Delay 4 Sec, Instant-Off. Wake-Up By PCI card...

  • Page 66: Pnp/Pci Configuration

    IMB200 LGA775 ATX MB User Manual PNP/PCI Configuration This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components.
  • Page 67 IMB200 LGA775 ATX MB User Manual Configuration Data (ESCD) once automatically. Disabled: The BIOS will not reset the configuration data. Resource controlled The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices.

  • Page 68: Pc Health Status

    IMB200 LGA775 ATX MB User Manual PC Health Status This option configures the PCI bus system. All PCI bus systems on the system use INT#, thus all installed PCI cards must be set to this value. Current System1 Temperature. The current system power will be detected automatically.

  • Page 69: Frequency/Voltage Control

    IMB200 LGA775 ATX MB User Manual SYSTEM FAN2 Speed. Show you the current system fan2 temperature +3.3V/+5V/+12V/-12V/-5V/VBAT(V)/5VSB Show you the voltage of +3.3V/+5V/+12V/-12V/-5V. 7.10 Frequency/Voltage Control CPU Clock Ratio This field is used to select the CPU’s frequency Auto Detect DIMM/PCI Clk Leave this field in its default setting.

  • Page 70: Load Fail-Safe Default

    IMB200 LGA775 ATX MB User Manual 7.11 Load Fail-Safe Default When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Fail-Safe Defaults (Y/N)? N Pressing “Y” loads the default values that are factory settings for optimal performance system operations 7.12 Load Optimized Default...
  • Page 71 IMB200 LGA775 ATX MB User Manual Set User Password: just can only enter but do not have the right to change the options of the setup menus. When you select this function, the following message will appear at the center of the screen to assist you in creating a password.

  • Page 72: Exit Setting

    IMB200 LGA775 ATX MB User Manual computer. You determine when the password is required within the BIOS Features Setup Menu and its Security option (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup.
  • Page 73 IMB200 LGA775 ATX MB User Manual Pressing <Enter> on this item asks for confirmation: Quit without saving (Y/N)? Y This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your compute...

  • Page 74: Appendix A Watchdog Timer

    IMB200 LGA775 ATX MB User Manual A p p e n d i x A Watchdog Timer Please follow the below WDT process for setup the WDT function. Watchdog Timer...

  • Page 75: Appendix B Pci Irq Routing

    IMB200 LGA775 ATX MB User Manual A p p e n d i x B PCI IRQ Routing PICMG PCI IRQ Routing Device Slot PCI Slot 1 CDAB PCI Slot 2 EFGH PCI Slot 3 FGHE PCI Slot 4 GHEF...
  • Page 76 IMB200 LGA775 ATX MB User Manual AppendixC Detailed memory Addess Mapping Detailed Memory Address Mapping...
  • Page 77 IMB200 LGA775 ATX MB User Manual AppendixD I/O Shield P/N was 728F2000100E I/O Shield...
