Technical Specifications

Specifications
Hardware Interface
Ports
Wireless Modem
Frequencies
Dimensions
Weight
Operating
Temperature
Humidity
Hardware
Connectors
Power*
Certifications and
Approvals
Max Outgoing Queue
Warranty
* Multi-Tech Systems, Inc. recommends that the customer incorporate a 10% buffer into their power source
when determining product load.
Multi-Tech Systems, Inc.
SF 100
Network: 10/100BaseT
Connector: RJ-45 Ethernet connection
ETHERNET: 1 Port
Quad-band GSM
850/900/1800/1900 MHz
6.4" w x 1.2" h x 6" d
(16.3 cm x 3.0 cm x 15.2 cm)
1.25 lbs.
(.56 kg)
o o o
+32 to +120 F (0 to +50
o
Note: UL listed @ +40 C (limited by the
power supply)
20–90% non-condensing
SIM connector: Standard 3V
Antenna: RF antenna 50 ohm SMA
(female)
External Power Supply
Input: 100-240Vac, 0.5A 50-60 Hz
Output: 9VDC, 1.7A
Power Consumption
Maximum power consumption is
0.95A at 9V
CE Mark; R&TTE
EMC Compliance:
FCC Part 15 Class A; EN 55022 Class A;
EN 55024; ACIF S042.1; ACIF S042.3
Radio Compliance:
FCC Part 22, 24
EN 301 489-1; EN 301489-7;
EN 301 511
RSS 132, 133, 102
Safety:
cUL 60950-1; UL 60950-1;
IEC 60950-1; AS/NZS 60950
Network Compliance:
PTCRB, GCF
4 MB
2 years
MultiModem® iSMS User Guide for Administrators
Chapter 1 – Safety Information and Product Description
SF 400/800
Network: 10/100BaseT
Connector: RJ-45 Ethernet connection
ETHERNET: 1 Port
Quad-band GSM
850/900/1800/1900 MHz
17.4" w x 1.75" h x 8.5" d
(44.2 cm x 4.5 cm x 21.6 cm)
SF 400: 7.75 lbs. (3.52 kg)
SF 800: 8.00 lbs. (3.64 kg)
o o
C) +32 to +120
20–90% non-condensing
SIM connector: Standard 3V
Antenna: RF antenna 50 ohm SMA
(female)
Power Supply – (Universal Input)
Input: 100-240Vac, 1.8 – 1.0 A
CE Mark; R&TTE
EMC Compliance:
FCC Part 15 Class A; EN 55022 Class A;
EN 55024; ACIF S042.1; ACIF S042.3
Radio Compliance:
FCC Part 22, 24
EN 301 489-1; EN 301489-7;
RSS 132, 133, 102
Safety:
cUL 60950-1; UL 60950-1;
Network Compliance:
PTCRB, GCF
10 MB
2 years
o o o
F (0 to +50 C)
50/60 Hz
EN 301 511
IEC 60950-1; AS/NZS 60950
13
