Chapter 3 – iSMS Basics and the Setup

Starting the iSMS

Open a Web Browser

Be sure that the MultiModem iSMS is cabled and that the power is connected as shown in
1.
Chapter 2.
Then open a Web browser.
2.
Type the default gateway address line: http://192.168.2.1
3.
Press Enter.
4.

Login

The Login screen for the MultiModem iSMS Web Interface displays.
•
Type admin (admin is the default user name) in the user name box.
•
Type admin in the password box.
•
Click Login.
Note: The User Name and Password entries are case-sensitive (both must be typed in lower-
case). The password can be up to 12 characters. Later, you will want to change the password
from the default (admin) to something else. If Windows displays the AutoComplete screen,
you may want to click No to tell the browser to not remember the password for security
reasons.
Password Caution:
safe password; a password such as xfT35$4 is better. It is recommended that you change the
default password. Create your own password.

Web Interface Opens

This is the Home screen from which you can access all setup functions.
Note: Only the top portion of the Home screen is shown here.
Multi-Tech Systems, Inc.
Wizard
Use a safe password! Your first name spelled backwards is not a sufficiently
MultiModem® iSMS User Guide for Administrators 19
