Chapter 4 Label Design

7. Line Field

34
A line can be printed in right angles along or across the media
path according to the print direction.
In addition to the general formatting commands, PRPOS,
ALIGN, and DIR, a line fi eld is specifi ed by a single command.
Set Size of the Line
The size of the line is specifi ed with regard to length and line
weight (thickness).
PRLINE | PL <length>,<line thickness>
<length>
<line thickness>
Default:
Summary
To create a line fi eld, the following formatting commands must
be given (in most cases default values may substitute missing
parameters). Printing commands are explained in Chapter 5.2.
Purpose
X/Y Position PRPOS | PP
Alignment
Direction
Line size
Example:
PP 100,100:AN 1:DIR 4:PL 200,10 ↵
EasyCoder E4 Direct Protocol v2.10 – Programmer's Reference Manual
the length of the line in dots along the
selected direction.
the line weight in dots.
No
Command Default
0,0
ALIGN | AN 1
DIR 1
PRLINE | PL n.a.
Remarks
Number of dots
Select ALIGN 1- 9
Select DIR 1-4
Length and line
thickness in dots
