7. Line Field

Intermec EasyCoder 301 Direct Protocol 2.0 – Programmer's Guide Ed. 3
A line can be printed in right angles along or across the paper ac-
cording to the print direction.
In addition to the general formatting commands, PRPOS, ALIGN
and DIR, a line field is specified by a single command.
Set Size of the Line
The size of the line is specified with regard to length and line weight
(thickness).
PRLINE | PL <length>,<line thickness>
<length>
<line thickness>
Default:
Summary
To create a line field, the following formatting commands must be
given (in most cases default values may substitute missing para-
meters). Printing commands are explained in chapter 5.2.
Purpose Command
X/Y Position PRPOS | PP
Alignment ALIGN | AN
Direction DIR
Line size PRLINE | PL
Example:
PP 100,100:AN 1:DIR 4:PL 200,10
Chapter 4
the length of the line in dots along the se-
lected direction.
the line weight in dots.
No
Default
0,0
1
1
n.a.
Label Design
Remarks
Number of dots
Select ALIGN 1 – 9
Select DIR 1 – 4
Length and line
thickness in dots
31
