5. Image Field
EasyCoder E4 Direct Protocol v2.10 – Programmer's Reference Manual
An image fi eld contains a black & white picture or logo in .PCX
format. The image can either be stored in the printer's RAM
or in a memory card. It can also be downloaded from the host
computer.
You cannot store images in the printer's ROM, but it does
contain two standard images: "ROM:GLOBE.1", which is a
sample image for DIR 1 and 3, and "ROM:GLOBE.2", which
is the same sample image for DIR 2 and 4.
In addition to the general formatting commands, PRPOS,
ALIGN, and DIR, an image fi eld can contain the following
commands:
• Name
• Magnifi cation
• Normal/Inverse printing
Select an Image
An image is selected by the full name under which it is stored
in the printer's memory, either as plain text or as a variable (also
see Chapter 4.9).
PRIMAGE | PM "<image name>"
<image name>
Default:
The Intermec image name convention includes an extension (.1
or .2), where .1 indicates that the image is intended for print
directions 1 and 3, whereas .2 indicates print directions 2 and 4
(see Chapter 4.2). For example, the image "ROM:GLOBE.1" is
suited for directions 1 and 3.
Set Image Magnifi cation
Images can be magnifi ed 1-4 times independently with regard to
height and width using a MAG command.
MAG <height mag>,<width mag>
<height mag>
<width mag>
Default:
Reset to default by:
To obtain the best printout quality, select a larger image rather
than magnifying a smaller one.
Chapter 4
the full name and storage location of
the image including extension, enclosed by
double quotation marks
None
the height magnifi cation factor (1-4 times).
the width magnifi cation factor (1-4 times).
1,1
PRINTFEED|PF
Label Design
31
