Chapter 13

Commands and Functions

1. Commands

Instruction
ALIGN (AN)
BARFONT (BF)
BARFONT (BF) ON/OFF
BARFONTD (BFD)
BARFONTDSIZE (BFSD)
BARFONTDSLANT (BFLD) 9.2
BARFONTSIZE (BFS)
BARFONTSLANT (BFL)
BARHEIGHT (BH)
BARMAG (BM)
BARRATIO (BR)
BARSET
BARTYPE (BT)
BREAK
110
Chapter
4.2
4.4
4.4
9.2
9.2
9.2
9.2
4.4
4.4
4.4
4.4, 9.1
4.4
6.16
EasyCoder E4 Direct Protocol v2.10 – Programmer's Reference Manual
Purpose
Specifi es which part of a text, bar code fi eld, image fi eld, line,
or box will be positioned at the insertion point.
Specifi es a single-byte character set font for printing human
readable bar code interpretation. The settings are: start
parameter; font name; font size in points; character slant
in degrees, with positive values slanting the characters to
the right; vertical offset between the bar code and the
interpretation; width magnifi cation; height magnifi cation;
enable/disable the printing of bar code interpretations.
Enables/disables the printing of bar code interpretations.
Specifi es a double-byte character set font for printing human
readable bar code interpretation. The settings are: font name;
font size in points; character slant in degrees.
Specifi es the font size of a double-byte character set in points
for printing human readable bar code interpretation.
Specifi es the slant of a double-byte character set font in degrees
for printing human readable bar code interpretation.
Specifi es the font size for a single-byte character set font in
points for printing human readable bar code interpretation.
Specifi es the slant of a single-byte character set font in degrees
for printing human readable bar code interpretation.
Specifi es the height of a bar code in dots.
Specifi es the magnifi cation with regard to the width of the bars
in a bar code.
Specifi es the width ratio between wide and narrow bars in a
bar code.
Specifi es a bar code type and sets parameters for complex bar
codes.
Specifi es the type of bar code.
Specifi es a break interrupt character separately for the parallel
and serial communication channels.
