Chapter 9

Advanced Features

1. Specifying Complex Bar Codes

72
Complex 2-dimensional bar or dot codes, for example PDF417,
require many specifying parameters. Therefore, there is a complex
command that allows all bar code parameters to be specifi ed
within a single command. This command can also be used for
one-dimensional bar codes (see Chapter 4.4).
BARSET[#<start parameter>,]["<bar code name>"[,<ratio wide bars>
[,<ratio narrow bars>[,<magnifi cation>[,<height> [,<security level>
[,<aspect ratio height>[,<aspect ratio width>[,<no. of rows>[,<no. of col-
umns> [,<truncate fl ag>]]]]]]]]]]]
<start parameter>
<bar code name>
<ratio wide bars>
<ratio narrow bars>
<magnifi cation>
<height>
<security level>
<aspect height ratio>
<aspect height width> only used in PDF417 and Maxicode
<no. of rows>
<no. of columns>
<truncate fl ag>
EasyCoder E4 Direct Protocol v2.10 – Programmer's Reference Manual
specifi es fi rst parameter in the command
(default 1)
specifi es bar code
(default "INT2OF5")
specifi es ratio wide/narrow bars
(default 3)
specifi es ratio wide/narrow bars
(default 1)
specifi es magnifi cation
(default 2)
specifi es height of bars in dots
(default 100)
only used in PDF417 and Maxicode
(default 2)
only used in PDF417 and Maxicode
(default 1)
(default 2)
only used in PDF417 and Maxicode
(default 0)
only used in PDF417 and Maxicode
(default 0)
only used in PDF417 and Maxicode
(default 0)
