Chapter 1. Introduction

FUNCTIONAL DESCRIPTION

Features

Interfaces

1-2
The Full Drop and Insert is designed to fit in the option slot
of the TSU 100/600 and is subject to its operation and control.
The D & I is configured from the front panel of the TSU 100/
600 or by an external personal computer (PC) using the
optional controlling software T-Watch. The internal menus
for its configuration are a part of the D & I option module
and are automatically installed when the D & I is plugged
into the unit.
The Full Drop and Insert option module has the following
features:
• Operates using 1 to 24 DS0s
• Operates as a Full Drop & Insert or as a passthru module
• Accommodates an additional plug-on (piggyback)
interface such as the Nx56/64 or OCU-DP
• Includes an elastic store and controlled frame slip
permitting loop timing on the network interface, as well
as on the D & I T1 circuit
• Provides timing for the TSU 100/600 as an option
• Displays menu options for easy configuration
• Includes a configurable DS0 assignment map
• Accumulates performance data on the T1 loop to which it
is attached
• Executes an extensive self-test
The Full Drop and Insert option module has the following
interfaces:
• Performance per ANSI T1.403 and AT&T 54016.
• RJ48C network interface connector
• AMI or B8ZS coding
• ESF or SF(D4) framing
Drop and Insert Option Module User Manual 61200065L1-1
