List of Figures
Figure 1-1. D & I Used With Two Separate T1s .................................................1-1
Figure 1-2. Full Drop and Insert Option Module ...............................................1-4
Figure 2-1. Installing Option Module ..................................................................2-2
Figure 3-1. TSU 100 Main Menu ...........................................................................3-2
Figure 3-2. Port Status Menu Path .......................................................................3-3
Figure 3-3. Secondary Interface Performance Report ........................................3-4
Figure 3-4. D & I Errors Display ...........................................................................3-6
Figure 3-5. Port Configuration Menu Path .........................................................3-7
Figure 3-6. DS0 Port Assignment .........................................................................3-8
Figure 3-7. DS0 Passthru Marking .......................................................................3-8
Figure 3-8. In Use Port Display .............................................................................3-9
Figure 3-9. DI Map Conflict Display ....................................................................3-9
Figure 3-10. Port Utility Menu Path .....................................................................3-10
Figure 3-11. Port Test Menu Path .........................................................................3-11
61200065L1-1 Drop and Insert Option Module User Manual xi
