Chapter 3

OVERVIEW

Menu Structure

Menu Operation

61200065L1-1
Operation
The Full Drop and Insert option module is controlled as part
of the TSU 100/600 using the same methods as described in
the user manual.
Refer to the TSU 100/600 User Manual for descriptions of front
panel indicators and buttons.
When an option module is installed in the TSU 100/600, the
unit adds it to the list of available options under the Port
menu items. These menu items are shaded in the limited
overview of the TSU 100 menu shown in Figure 3-1. (A
complete menu diagram is shown in the appendix of the
TSU 100 User Manual.)
An option module must be selected from the listing in one of
the Port menu options before its menus are applicable. With
the cursor on one of the Port menu items, press
display a list of the currently installed option modules. To
activate menus for the Full Drop and Insert option module
scroll through the list to display 1.1 Full D & I and press
.
Enter
Once the option module is selected, the D & I menus appear
as a subset of, and operate the same as, menus for the TSU
100/600. With the cursor on one of the TSU 100/600 four
Drop and Insert Option Module User Manual
to
Enter
3-1
