Wiring

POWER UP TESTING

Successful Self Test

61200065L1-1
The D & I module offers a single connector for interface to the
T1 circuit. The pinout is given in Table 2-1 Network Pinout
Connection.
The required wiring connection is:
Connector Type (USOC) = RJ48C
Pin
1
2
3
4
5
6, 7, 8
The Full Drop and Insert option module executes a self-test
during the power-up sequence, as described in the TSU 100/
600 User Manual. No initialization input is required. Any
previously configured setting for the D & I is restored
automatically upon power-up.
The yellow TEST LED, located with the Module LEDs on the
front panel, extinguishes when self-test is completed and the
configuration is successfully restored. See Front Panel
Operation, TSU 100/600 User Manual.
Drop and Insert Option Module User Manual
Table 2-1. Network Pinout Connection
Name
R1 RXDATA
T1 RXDATA
Unused
R TXDATA
T TXDATA
Unused
Chapter 2. Installation
Description
Receive Data
Receive Data
-
Send Data
Send Data
-
2-3
