EXULUS
Spatial Light Modulators
Chapter 4: Setup and Software Operation
User defined patterns (up to 50 frames) are supported in the sequence table. The
default interval is 300 ms.
The four control buttons from left to right are "Add to Sequence", "Remove from
Sequence", "Play Sequence" and "Stop Sequence".
Add to Sequence
Add the current preview pattern into the sequence table.
Remove from Sequence
Remove the selected pattern from the sequence table.
Play the Sequence
Run the sequence with defined interval. While playing the sequence, this button
can be used to temporarily pause the sequence playing.
Stop the Sequence
Stop and quit the sequence mode.
4.5.6.
Status Bar
The status bar displays information about the system status, actual temperature
reading from the liquid chiller (if connected) and the SLM device status.
Page 40
CTN013676-D02
