EXULUS
Spatial Light Modulators
and configure the SLM display in Extended Mode.
Then, run the application software "Thorlabs EXULUS" from the desktop icon. It
may take several seconds before the software is ready to connect.
4.5.
Software GUI
The Software GUI provides complete control of SLM panel. If a High-Power SLM
is used, the temperature reading from the liquid chiller (Item # LK220) is also
available. It is divided into six functional areas:
•
Main Menu
•
Sequence Setting
•
Preview Window
•
Operation Mode
•
Display Mode
•
Status Bar
Figure 37 Main UI Window of EXULUS SLM Software
Page 28
Chapter 4: Setup and Software Operation
Main Menu
Sequence
Settings
Preview
Window
Operation
Mode
Display
Mode
Status
Bar
CTN013676-D02
