Chapter 2: Jumpers and Connectors
Power Button
Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP2
1
2
Pin
Definition
1
PWRBT
2
GND
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Reset Button
Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP1
1
2
Pin
Definition
1
GND
2
RESET
15
eLITE610 User Manual
