Nexcom eLITE610 User Manual page 62

Chapter 4: BIOS Setup
PCI Express Configuration
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Advanced
Main Chipset Boot
PCI Express Configuration
LAN1
LAN2
MINIPCIE1
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
LAN1 and LAN2
Enables or disables LAN1 or LAN2 ports.
MINIPCIE1
Enables or disables Mini-PCIe1 port.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Save & Exit
Security
Control the PCI Express Root
Port.
AUTO: To disable unused root
port automatically for the most
optimum power savings.
Enable: Enable PCIe root port
Disable: Disable PCIe root port
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
SATA Drives
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Advanced
Main Chipset
SATA Drives
Chipset-SATA Controller Configuration
Chipset SATA
MSATA
MSATA
SATA
SATA
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
Chipset SATA
Enables or disables the SATA controller chipset. The SATA controller chipset
supports the 2 black internal SATA ports (up to 3Gb/s supported per port).
MSATA
Enables or disables the mSATA port.
SATA
Enables or disables the SATA port
48
Save & Exit
Boot Security
Enables or disables the SATA
controller chipset. The SATA
controller chipset
supports the 2 black internal
[Enable]
SATA ports (up to 3Gb/s sup-
[Not Installed]
ported per port).
[Enabled]
[Not Installed]
[Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
eLITE610 User Manual
