Chapter 2: Jumpers and Connectors

TPM/Debug Port Connector

Connector type: 1x10 10-pin header, 1.0mm pitch
Connector location: DEBUG1
10 1
Pin Definition
1 GND
3 LPC_CLK
5 LPC_AD3
7 LPC_AD1
9 LPC_SERIRQ
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 Reset#
4 LPC_FRAME#
6 LPC_AD2
8 LPC_AD0
10 3.3V

EC Programming Connector

Connector type: 1x3 3-pin header, 1.25mm pitch
Connector location: JP8
3 1
Pin Definition
1 GND
2 EC_I2CDATA
3 EC_I2CCLK
20
