Internal Connectors; Dc Input Connector - Nexcom eLITE610 User Manual

Chapter 2: Jumpers and Connectors

Internal Connectors

DC Input Connector

Connector type: 1x4 4-pin header, 2.0mm pitch
Connector location: JP3
1 4
Pin Definition
1 12V
3 12V
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 12V
4 12V
DC Input Connector
Connector type: 1x4 4-pin header, 2.0mm pitch
Connector location: JP4
1 4
Pin Definition
1 12V
3 12V
14
Pin Definition
2 12V
4 12V
eLITE610 User Manual
