Chapter 4: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on
the screen. The main menu allows you to select from several setup functions
and one exit. Use arrow keys to select among the items and press
accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS
Setup Utility.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Main Advanced Chipset Security
BIOS Vendor American Megatrends
Core Version 5.12
Compliancy UEFI 2.5; PI 1.4
Project Version APLO- 0.05 x64
Build Date and Time 12/21/2016 16:09:58
EC Version C 00 3
Access Level Administrator
Platform firmware Information
BXT SOC B1
MRC Version 0.56
PUNIT FW 1E
PMC FW 03.24
TXE FW 3.0.10.1129
ISH FW 4.1.0.3359
GOP 10.0.1033
CPU Flavor BXT Notebook/Desktop...
Oxbow Hill CRB (06)
Board ID
Fab ID FAB A
Memory Information
Total Memory 4096 MB
Memory Speed 1866 MHz
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
▲
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Main Advanced Chipset
Build Date and Time
EC Version
Access Level
to
Platform firmware Information
BXT SOC
MRC Version
PUNIT FW
PMC FW
TXE FW
ISH FW
GOP
CPU Flavor
Board ID
Fab ID
Memory Information
Total Memory
Memory Speed
System Language
System Date
System Time
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
System Language
Selects the language of the system.
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day,
from Monday to Sunday. Month displays the month, from January to
December. Date displays the date, from 1 to 31. Year displays the year, from
1999 to 2099.
System Time
The time format is <hour>, <minute>, <second>. The time is based on the
24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays
hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays
seconds from 00 to 59.
38
Security Boot Save & Exit
▲
12/21/2016 16:09:58
Choose the system default
C 00 3 language
Administrator
B1
0.56
1E
03.24
3.0.10.1129
4.1.0.3359
10.0.1033
BXT Notebook/Desktop...
Oxbow Hill CRB (06)
FAB A
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
4096 MB
F1: General Help
1866 MHz
F2: Previous Values
F3: Optimized Defaults
[English]
F4: Save & Exit
ESC: Exit
[Tue 12/27/2016]
[09:29:04]
▼
