Chapter 1: Product Introduction
Hardware Specifications
Main Board
▪ Intel
®
Comet Lake processor (LGA1200), up to 80W
▪ Intel
W480
®
▪ TPM 2.0 (optional)
▪ Dual BIOS
Main Memory
▪ 2 x DDR4 2666/2933 ECC/non-ECC UDIMM, up to 32GB
Storage
▪ 2 x 2.5" internal SSD/HDD bays
▪ 1 x M.2 2242 Key M (SATA)
▪ 1 x SATA3 for SATA DOM
I/O Interface-External
▪ Button: power & reset
▪ LED: HDD/GPIO
▪ 2 x USB 3.0 ports
▪ 1 x RJ45 console
▪ 8 x 2.5 GbE RJ45 LAN ports
▪ 1 x LAN module slot
▪ 1 x HDMI
I/O Interface-Internal
▪ 2 x Fixed smart fans
▪ 1 x Power inlet
▪ 1 x Low profile standard PCIe x8 expansion slot
▪ LCM
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Riser Card
▪ NVMe with 2 x M.2 SSD
Power Input
▪ 300W single power supply
Dimensions and Weight
▪ Chassis dimension: 430 mm x 300 mm x 44 mm
▪ Carton dimension: 544 mm x 506 mm x 205 mm
▪ Without packing: 4.7 kg
▪ With packing: 7.5 kg
Environment
▪ Operating temperatures: 0°C~40°C
▪ Storage temperature: -40°C~80°C
▪ Relative humidity: 10%~90% non-condensing
2
NSA 3190A User Manual
