Chapter 2: Jumpers and Connectors
LAN1 to LAN8 Ports
Connector type: RJ45 with LEDs
Connector location: LAN1
ACT
LINK
8
1
Pin
Definition
1
MDI0P
3
MDI1P
5
CT
7
MDI2P
9
MDI3P
11
Speed LED
13
Active LED
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Act
Status
Flashing Green
Data activity
Steady Green
No activity
Link
Status
Steady Green
1G network link
Steady Amber
100Mbps network link
Off
10Mbps or no link
Pin
Definition
2
MDI0N
4
MDI1N
6
CT
8
MDI2N
10
MDI3N
12
Speed LED
14
Active LED
LAN9 to LAN16 Ports with PoE (Optional)
Connector type: RJ45 with LEDs
Connector location: LAN2
ACT
LINK
8
1
Pin
Definition
1
CT
3
MDI2P
5
MDI2N
7
CT
9
MDI3N
11
MDI0P
13
Type A POE+
15
Type B POE+
11
Act
Status
Flashing Green
Data activity
Steady Green
No activity
Link
Status
Steady Green
1G network link
Steady Amber
100Mbps network link
Off
10Mbps or no link
Pin
Definition
2
MDI2N
4
MDI1P
6
CT
8
MDI3P
10
MDI0N
12
CT
14
Type A POE-
16
Type B POE-
NSA 3190A User Manual
