Chapter 4: BIOS Setup
Hardware Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc.
Advanced
Pc Health Status
VCORE : +0.871 V
P12V : +12.168 V
: +4.940 V
P5V
P3V3 : +3.250 V
VDDQ : +1.209 V
PECI Temperature : +38 C
FAN 1 Speed(CN1) : N/A
FAN 2 Speed(CN4) : N/A
FAN 3 Speed(CN2) : 5794 RPM
FAN 4 Speed(CN3) : N/A
FAN 1 Setting(CN1)
FAN 1 OUT Mode [Smart Fan]
FAN 2 Setting(CN4)
FAN 2 OUT Mode [Smart Fan]
FAN 3 Setting(CN2)
FAN 3 OUT Mode [Smart Fan]
FAN 4 Setting(CN3)
FAN 4 OUT Mode [Smart Fan]
Version 2.21.1278. Copyright (C) 2020 American Megatrends, Inc.
FAN 1 to FAN 4 OUT Mode
Configures the operating mode of fan 1 to fan 4.
FAN Min Temperature
Configures the temperature to turn the fan off.
FAN Max Temperature
Configures the temperature to turn the fan on.
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
▲
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
47
Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc.
Advanced
FAN 3 Speed(CN2) : 5825 RPM
FAN 4 Speed(CN3) : N/A
FAN 1 Setting(CN1)
FAN 1 OUT Mode [Smart Fan]
FAN 2 Setting(CN4)
FAN 2 OUT Mode [Smart Fan]
FAN 3 Setting(CN2)
FAN 3 OUT Mode [Smart Fan]
FAN 4 Setting(CN3)
FAN 4 OUT Mode [Smart Fan]
SMART FAN Setting
FAN Min Temperature 20
FAN Max Temperature 90
FAN Min PWM 95
FAN Max PWM 175
Tolerance Temperature 3
Version 2.21.1278. Copyright (C) 2020 American Megatrends, Inc.
FAN Min PWM
Configures the start PWM value of the fan. This is used to set the starting
fan speed.
FAN Max PWM
Configures the maximum PWM value of the fan.
Tolerance Temperature
Configures the minimum and maximum temperature threshold to activate
smart fan.
▲
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
