Page 1 HARDWARE INSTALLATION GUIDE Brocade MLX Series and Brocade NetIron XMR Installation Guide Supporting NetIron OS 6.0.00 53-1004195-02 29 April, 2016...
Page 2 The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.
Page 3: Table Of Contents
................. 43 Installation procedure Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 4 ................119 Activating the power source Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 5 ................. 190 Forced card deletion Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 6 ..........220 Line Module Configuration Deletion in Interactive Boot Mode Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 7 ................257 Replacing a power supply Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 8 ....................304 Dangers viii Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 9: Preface
In Fibre Channel products, a fixed value provided as input to a command option is printed in plain text, for example, --show WWN. Syntax components displayed within square brackets are optional. Default responses to system prompts are enclosed in square brackets. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 10: Notes, Cautions, And Warnings
Brocade website. Contacting Brocade Technical Support As a Brocade customer, you can contact Brocade Technical Support 24x7 online, by telephone, or by e-mail. Brocade OEM customers contact their OEM/Solutions provider. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 11: Brocade Customers
By sending your feedback to documentation@brocade.com. Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 12 Document feedback Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 13: About This Document
In instances in which procedures or parts of procedures documented here apply to some devices but not to others, this guide identifies exactly which devices are supported and which are not. Although many different hardware configurations are tested and supported by Brocade Communications Systems, Inc., documenting all possible configurations and scenarios is beyond the scope of this document.
Page 14 DRAFT: BROCADE CONFIDENTIAL What’s new in this document Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 15: Product Overview
Brocade MLX routers are available in the following models: • Brocade MLX-4: 4 interface slots (see <Link>Figure 1 on page 2) • Brocade MLX-8: 8 interface slots (see <Link>Figure 2 on page 3) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 16 Brocade MLX-4 router components You can install the following components in the router slots: • Up to two management modules (one active and one redundant).Brocade MLX Series and Brocade NetIron XMR Installation Guide • Up to three switch fabric modules.
Page 17 Up to two management modules (one active and one redundant). • Up to four switch fabric modules. • Up to 16 interface modules. • Up to eight power supplies (AC or DC). <Link>Figure 3 displays the Brocade MLX-16 router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 18 Two management modules. • Up to eight switch fabric modules. • Up to 32 interface modules. • Up to eight power supplies (AC or DC). <Link>Figure 4 displays the Brocade MLX-32 router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 19 Power supply 8 Switch fabric slot 3 Management slot 1 Power supply 3 Switch fabric slot 4 Management slot 2 Power supply 4 Switch fabric slot 5 Captive screws Power supply 5 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 20: Netiron Xmr Routers
NetIron XMR 8000 router components You can install the following components in the router slots: • Up to two management modules (one active and one redundant). • Up to three switch fabric modules. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 21 • Up to four switch fabric modules. • Up to 16 interface modules. • Up to eight power supplies (AC or DC) <Link>Figure 7 displays the NetIron XMR 16000 router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 22 Up to two management modules (one active and one redundant). • Up to eight switch fabric modules. • Up to 32 interface modules. • Up to eight power supplies (AC or DC). Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 23 Power supply 6 Switch fabric slot 1 Switch fabric slot 7 Power supply 1 Power supply 7 Switch fabric slot 2 Switch fabric slot 8 Power supply 2 Power supply 8 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 24: Router Modules
MR management module • MR2 management module <Link>Table 1 lists the management modules available for Brocade MLX and NetIron XMR routers. TABLE 1 Management modules for all Brocade MLX Series and NetIron XMR routers Part number Description NI-MLX-MR (MR) Brocade MLXe and Brocade MLX management module, 1 GB SDRAM, dual auxiliary flash slots, EIA or TIA-232 and 10/100/1000 Ethernet ports for out-of-band management.
Page 25 For information about the redundancy feature, refer to the “Using a Redundant Management Module” chapter in the Brocade MLX Series and Brocade NetIron Family Configuration Guide. Management modules are installed in dedicated slots marked M1 and M2. By default, the module installed in slot M1 is the active management module.
Page 26 The existing management network into which you can connect the 10/100/1000 Ethernet port must be separate and isolated from the network over which user packets are switched and routed. For information about the functionality of the management port, refer to <Link>“Understanding management port functions” on page 206. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 27: Interface Modules
• Gen-2 interface modules, which provide additional functionality, more memory, and higher operation speeds. <Link>Table 3 lists the interface modules that are available for Brocade MLX Series and NetIron XMR routers. TABLE 3 Interface modules for all Brocade MLX Series and NetIron XMR routers...
Page 28 Router modules TABLE 3 Interface modules for all Brocade MLX Series and NetIron XMR routers (Continued) Ports Description BR-MLX-100GX-1 MLXE/XMR/MLX 1-port 100-GbE (X) Module with IPv4/IPv6/MPLS hardware support - requires CFP optics. Supports 1M IPv4 routes in FIB in XMR mode and 512K IPv4 routes in MLX mode.
Page 29 100xGbE 2-port interface module The 100xGbE 2-port interface module is supported on all Brocade MLX Series and NetIron XMR routers. This interface module has two 100 Gbps CFP optics ports, 2 Gbps memory, an internal flash of 32MB for local storage of CPU images, and 64MB for local storage of FPGA images.
Page 30 For more information about fiber-optic transceivers and associated cabling, refer to <Link>“Installing a fiber-optic transceiver” on page 207. Power supply requirements for 100xGbE modules For power supply requirements for the 100xGbE modules, refer to <Link>“Hardware Specifications”. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 31 For Brocade XMR 16-slot routers, 8x10GE-X modules require the installation of high-speed fans in addition to high-speed switch fabric modules. For information about the high-speed fans, see <Link>“NIBI-16-FAN-EXH-A high-speed fan assemblies” on page 38. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 32 For more information on the appropriate software release refer to the Hardware Installation Notes that shipped with the interface module. <Link>Figure 14 shows Gen-1 2-port and 4-port 10 Gbps Ethernet interface module front panels. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 33 Brocade Optics Family Data Sheet, available online in the following location: http://www.brocade.com/downloads/documents/data_sheets/product_data_sheets/optics-family-ds.pdf For more information about fiber-optic transceivers and associated cabling, refer to <Link>“Installing a fiber-optic transceiver” on page 207. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 34 You must insert XFP-compliant fiber-optic transceivers in each port you intend to use. XFP-compliant transceivers provide an optical or physical medium-dependent (PMD) interface for single- or multi-mode fiber that can be used with either the LAN physical layer (PHY) or WAN physical layer (WAN PHY). Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 35 <Link>Figure 16 displays the faceplate of the NI-MLX-10Gx8-M and NI-MLX-10Gx8-D modules. <Link>Figure 17 shows the RX and TX orientation for the ports, and identifies which LED goes with which port. FIGURE 16 NI-MLX-10Gx8-M and NI-MLX-10Gx8-D module faceplate Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 36 Module 7 is -d class, it can't work when router mpls is enabled. Reset slot 7 SYSLOG: May 28 16:22:48 :<13>May 28 16:22:48 Module 7 is reset by mgmt (reason: boot to interactive mode) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 37 LEDs to the left support the top ports, LEDs to the right support the bottom ports • 24 1 Gbps RJ45 copper ports <Link>Table 10 describes the LEDs for the BR-MLX-1GCx24-X interface module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 38 When installing 24-port copper or fiber interface modules, you must change the ifIndex allocation to 64 before you install the module, or the module will not operate properly when installed. <Link>Figure 19 shows the front panel of the BR-MLX-1GFx24-X and BR-MLX-1GFx24-X-ML fiber interface modules. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 39 LEDs to the left support the top ports, LEDs to the right support the bottom ports • 20 100/1000 Ethernet SFP ports <Link>Table 12 describes the LEDs for the 20-port 100/1000 Ethernet module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 40 A link is not established with the remote port and no traffic is being passed. NI-MLX-1Gx48-T-A interface module <Link>Figure 22 shows the front panel of the NI-MLX-1Gx48-T-A interface module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 41 Power 2: Installed (Failed or Disconnected) Power 3: not present Power 4: Installed (Failed or Disconnected) Power 5: (H1250CFN - AC 1200W): Installed (OK) Power 6: (30351200 - AC 1200W): Installed (OK) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 42 Name of the module. • Number of ports and the type of ports. • LED indicator for a port. • LED indicator for module power. <Link>Table 14 describes the BR-MLX-40Gx4-M module LEDs. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 43: Forward Error Correction (Fec) Mode
• All fabric facing links on the 4x40G, 2x100G and 24x10G TMs will have FEC enabled • hSFM links connected to 4x40G, 2x100 and 24x10 will have FEC enabled Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 44: Switch Fabric Modules
Brocade MLX Series and NetIron XMR router switch fabric modules are dedicated, which means that they function properly in these routers only. If you attempt to install a Brocade MLX Series or NetIron XMR router switch fabric module in another Brocade device or a switch fabric module intended for another Brocade device in a Brocade MLX Series or NetIron XMR router, the router and switch fabric module will not function properly.
Page 45: High-Speed Switch Fabric Modules
HSF modules are supported on Brocade MLX Series and NetIron XMR routers, and are interoperable with all existing interface modules. HSF modules are hot-swappable, which means you can install or replace them while the system is powered up and running.
Page 46: Power Supplies
32-Slot NetIron MLXe/XMR/MLX AC 2400W power supply. NIBI-32-DCPWR 32-Slot NetIron MLXe/XMR/MLX DC 2400W power supply. Brocade MLX Series and NetIron XMR routers support the following power supply options: • 4-slot router: Can accommodate three 1200W power supplies. For power redundancy you must purchase additional power supplies depending on how you populate your router.
Page 47 Power supply interoperability For Brocade MLX Series and NetIron XMR 32-slot devices, you can mix 2400W and 3000W power supply units. For Brocade MLX and NetIron XMR devices, only the 8-slot and 16-slot router power supplies are interchangeable. The 4-slot and 32-slot power supplies cannot be used in 8-slot or 16-slot Brocade MLX or NetIron XMR devices.
Page 48: Rack Mounting Brackets
<Link>Figure 26 and <Link>Figure 27 show the fan locations for 4-slot and 8-slot routers. <Link>Figure 28 and <Link>Figure 29 show the fan locations for 16-slot routers. <Link>Figure 30 shows the fan locations for 32-slot routers. FIGURE 26 Fan locations for Brocade MLX and NetIron XMR 4-slot routers Fan module Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 49 FIGURE 27 Fan locations for Brocade MLX and NetIron XMR 8-slot routers Fan module FIGURE 28 Front fan location for Brocade MLX and NetIron XMR 16-slot routers Front fan assembly Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 50 Router modules FIGURE 29 Rear fan location for Brocade MLX and NetIron XMR 16-slot routers Rear fan assemblies Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 51 The system can also shut down the module if the temperature exceeds the highest threshold. You can change default low and high temperature thresholds for modules and fan speeds. Refer to <Link>“Changing temperature thresholds for modules and fan speeds” on page 222. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 52: Nibi-16-Fan-Exh-A High-Speed Fan Assemblies
Supported software features For a complete list of software features supported on Brocade MLX Series and NetIron XMR routers, refer to the Brocade MLX Series and Brocade NetIron Family Configuration Guide. Brocade MLX Series and Brocade NetIron XMR Installation Guide...
Page 53: Installing A Brocade Mlx Router
The procedures in this manual are for qualified service personnel. All fiber-optic interfaces use Class 1 Lasers. Do not install the device in an environment where the operating ambient temperature might exceed 40ºC (104ºF). Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 54 If you do not install a module in a slot, you must keep the slot blank in place. If you run the device with an uncovered slot, the system may overheat. Never leave tools inside the device. In order to protect the device from damage, utilize the original packaging when shipping the device. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 55: Power Precautions
Compare this total with the rating limit for the circuit. The maximum ampere ratings are usually printed on the devices near the input power connectors. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 56 The connector must be crimped with the proper tool, allowing it to be connected to both ground screws on the enclosure. Before crimping the ground wire into the provided ground lug, ensure the bare copper wire has been cleaned and antioxidant is applied to the bare wire. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 57: Installing 2X100Gbe Interface Modules In Brocade Mlx Routers
Brocade# reload NOTE The system-init tm-credit-size command is only available in R05.2.00 or later, so it is important to upgrade all software to R06.0.00 before you install your 2x100G module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 58 Figure NOTE Do not use the port cover tabs to lift the module. They are not designed to support the weight of the module, which can fall and be damaged. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 59 Clean all fiber cables properly before you connect them to the 2x100G interface module. FIGURE 33 Installing 2x100G modules in a 4- or 8-slot device (4-slot shown) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 60: Installing A Brocade Mlx-4 Router
The Brocade MLX-4 router ships with the following items: • Router chassis with switch fabric modules installed in slots marked SF, and slot blanks installed in all empty module slots. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 61: Installing A Brocade Mlx-4 Router In A Rack
You will need to provide four standard #12-24 pan-head screws per router and a #2 Phillips screwdriver to secure each router in the rack. Follow these steps to mount a Brocade MLX-4 router in a rack. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 62 FIGURE 37 Mounting the Brocade MLX-4 router in a rack (front-mount configuration) Standard 19-inch rack 2 Mounting screws Slide the router down so that the mounting screw heads are in the narrowest part of the keyhole slots. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 63: Installing Brocade Mlx-4 Modules
If you are installing a redundant management module, refer to the chapter titled “Using a Redundant Management Module” in the Brocade MLX Series and Brocade NetIron Family Configuration Guide for information about how the redundant module works, optional software configurations, and how to manage redundancy.
Page 64 If you are installing a module in a slot which may have been configured for a different module type, remove the old configuration information by following these steps. Use the show running-config command in config mode to determine the current configuration of the slot. Brocade(config)# show running-config Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 65: Installing Brocade Mlx-4 Router Power Supplies
FIGURE 38 Installing a module Installing Brocade MLX-4 router power supplies You need a small Phillips or flat-blade screwdriver to install power supplies. Follow these steps to install a power supply in the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 66: Connecting Ac Power
For the NEBS-compliant installation, AC power connections must use a surge protection device (SPD) to protect the AC power supplies from damage due to excessive power line surges. Follow these steps to connect the AC power cord: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 67: Connecting Dc Power
Because there are multiple power supply vendors, the LED layout on your DC power supply may differ from what is shown in Figure 41. However, the LED functions are identical. Follow these steps to connect a DC power source: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 68 To ensure adequate bonding when attaching the ground lug, a minimum of 20 PSI of torque is required to be applied to the mounting hardware used to attach the ground lug. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 69: Final Steps
“Attaching a management station” page 118, and “Connecting the router to a network device” on page 207. Unpacking a Brocade MLX-8 router The Brocade MLX-8 router ships with the following items: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 70: Installing A Brocade Mlx-8 Router In A Rack
Follow these steps to mount a router in a rack. NOTE You will need a Phillips screwdriver and four standard #12-24 pan-head screws (per router) to mount the router in a rack. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 71 Mount the lowest router first. With two or more people lifting the router, slip the widest part of each keyhole slot on the mounting bracket over the corresponding mounting screw in the rack post. See Figure FIGURE 45 Mounting the router in a rack (front-mount configuration) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 72: Installing Brocade Mlx-8 Modules
If you are installing a redundant management module, refer to the chapter titled “Using a Redundant Management Module” in the Brocade MLX Series and Brocade NetIron Family Configuration Guide for information about how the redundant module works, optional software configurations, and how to manage redundancy.
Page 73 If you are installing a module in a slot which may have been configured for a different module type, remove the old configuration information by following these steps. Use the show running-config command in config mode to determine the current configuration of the slot. Brocade(config)# show running-config Current configuration: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 74 Push the ejectors in until they are flush with the module front panel to fully seat the module in the backplane. Modules have a snug fit for maximum EMI protection. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 75: Installing Brocade Mlx-8 Router Power Supplies
Pull the latch handle on the power supply up to lock the power supply in place. For information about connecting power to the router, refer to “Connecting AC power” on page 62, or “Connecting DC power” page 63. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 76: Connecting Ac Power
The mark is your assurance that the power cord can be used safely with the router. For information about powering on the system, refer to “Activating the power source” on page 119. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 77: Connecting Dc Power
Before crimping the ground wire into the provided ground lug, ensure the bare copper wire has been cleaned and antioxidant is applied to the bare wire. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 78: Final Steps
Complete these final steps in the order listed: • “Attaching a management station” • “Activating the power source” • “Verifying proper operation” Installing a Brocade MLX-16 router This section describes how to install a Brocade MLX-16 router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 79: Preparing The Installation Site
You can install up the three Brocade MLX-16 routers in a standard 19-inch (EIA310-D) rack. It is recommended that you install your router in a rack before you install any router components. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 80 Starting at the bottom of the rack, mount the router as shown in Figure 52. With two or more people lifting the router, slip the wide portion of each keyhole slot over the corresponding mounting screw in the rack post. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 81: Installing Brocade Mlx-16 Router Modules
When installing a module in an empty device (with all slots covered by filler panels), first slightly loosen the screws on all of the filler panels. If you do not loosen all of the filler panel screws, the fit will be too tight when you install a module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 82 NIBI-16-FAN-EXH-A high-speed fan modules. For more information about high-speed fan modules, see “NIBI-16-FAN-EXH-A high-speed fan assemblies” on page 39. If the 16-slot router is not upgraded to support NIBI-16-FAN-EXH-A modules before NI-MLX-1GX48-T-A modules are installed, the following Syslog message is displayed. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 83 Bottom fan tray (fan 5): Status = OK, Speed = LOW (50%) Bottom fan tray (fan 6): Status = OK, Speed = LOW (50%) Rev A Back Fan A (revision 0x09): Status = OK, Speed = LOW (50%) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 84 If you are installing a redundant management module, refer to the chapter titled “Using a Redundant Management Module” in the Brocade MLX Series and Brocade NetIron Family Configuration Guide for information about how the redundant module works, optional software configurations that you can perform, and how to manage the redundancy feature.
Page 85 Enter the write memory command to ensure that the slot will be correctly configured for the new module after a reboot. Brocade(config)# write memory Write startup-config done. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 86: Installing Nibi-16-Fan-Exh-A Fan Assemblies
When installing NI-MLX-1Gx48-T-A modules, you must upgrade the software on all installed interface modules and management modules to the appropriate software release. For more information refer to the <Italic>Multi-Service IronWare Software Release 06.0.000 for Brocade MLX Series and Brocade NetIron Family. For more information on upgrading the software, refer to the Multi-Service IronWare Software Upgrade Guide.
Page 87 Remove the standard fan assemblies by inserting your fingers underneath each assembly and pulling it toward you as shown in Figure Be careful not to insert your fingers into the fan while removing it. The fan may still be spinning at a high speed. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 88 Insert the high-speed fan assembly into the fan slot and push the assembly in until the connection plate is flush with the device. Pushing the assembly in seats the fan connector with the device connector. Refer to Figure Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 89 Slot5 pri=1 module type=NI-MLX-10Gx8-M 8-port 10GbE (M) Module power usage=246W Slot6 pri=1 module type=NI-MLX-10Gx4 4-port 10GbE Module power usage=225W Slot7 pri=1 module type=NI-MLX-10Gx4 4-port 10GbE Module power usage=225W Slot8 pri=1 module type=NI-MLX-10Gx8-M 8-port 10GbE (M) Module power usage=246W Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 90: Installing Brocade Mlx-16 Router Power Supplies
Installing Brocade MLX-16 router power supplies High Touch Current. Earth connection is essential before connecting supply. Follow these steps to install a power supply in a Brocade MLX-16 router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 91 Carefully follow the mechanical guides on each side of the power supply slot and make sure the power supply is properly inserted in the guides. Never insert the power supply upside down. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 92: Connecting Ac Power
Locate the power supply AC Inlet at the bottom rear of chassis for the associated installed power supply as shown in Figure Lift the cord-retainer and connect an AC power cord to the power supply. Refer to Figure Snap the cord-retainer over the power plug to hold it in place. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 93 The mark is your assurance that the power cord can be used safely with the device. For information about powering on the system, refer to “Activating the power source” on page 119. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 94: Connecting Dc Power
To ensure adequate bonding when attaching the ground lug, a minimum of 20 PSI of torque is required to be applied to the mounting hardware used to attach the ground lug. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 95: Final Steps
103, “Installing power supplies in a Brocade MLX-32 router” on page 113, “Attaching a management station” on page 118, and “Connecting the router to a network device” on page 207. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 96: Unpacking A Brocade Mlx-32 Router
Use a power drill with Phillips and large flat-blade screwdriver attachments to remove the bolts and screws that hold the front shipping crate panel in place, as shown in Figure 60. Remove the front panel and set it aside. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 97: Installing A Brocade Mlx-32 Router In A Rack
You can mount one 32-slot router in a standard 19-inch (EIA310-D) rack or in an open frame rack. You must provide eight standard #12-24 pan-head screws to secure the router in the rack. You will need a #2 Phillips screwdriver to perform this task. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 98 A strap to secure and stabilize the device while it is being moved on the mechanical lift • A power drill with the following attachments: Large #2 Phillips screwdriver attachment A 7/16 inch socket wrench attachment Large 3/8 inch flat blade screwdriver attachment Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 99 Position the mechanical lift equipped with a lift plate as close to the front of the router as possible. Adjust the lift plate height so that it is even with the bottom of the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 100: Installing A Brocade Mlx-32 Router
The appropriate number of interface modules, switch fabric modules, management modules, and power supplies (four AC or four DC) in separate shipping cartons. • 32 slot blanks in separate shipping carton. • Insertion or extraction tool for use with RJ45 and fiber-optic connectors. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 101: Unpacking Your Brocade Mlx-32 Router
FIGURE 62 Removing bolts and screws and the front panel of the shipping crate Remove the remaining bolts and screws that attach the bottom of the crate to the pallet. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 102: Installing A Brocade Mlx-32 Router In A Rack
• Ensure that the rack is mechanically secured to support the router model.Ensure that the airflow available at the inlet air vents does not exceed 40 Celsius (104 Fahrenheit). Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 103 Position the mechanical lift equipped with a lift plate as close to the front of the router as possible. Adjust the lift plate height so that it is even with the bottom of the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 104 Use the screws specified for the type of rack. Make sure you have the items listed above and shown in Figure FIGURE 63 Open Frame EIA 310-D Rack Mount Kit contents Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 105 #12-24, #10-32, or M6, as appropriated for your rack (four screws on each post, in the three top holes and one bottom hole). See Figure NOTE Additional screws may be used for more support. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 106 Installing a Brocade MLX-32 router FIGURE 64 Align the saddle in the rack Saddle Seat of saddle aligns with U marking on mounting posts as shown FIGURE 65 Saddle installation Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 107 Visually inspect the alignment of the router. If the router is installed properly, the mounting screws on both sides rack should be aligned with the mounting screws on the opposite side and the router should be level. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 108 10. Visually inspect the alignment of the router. If the router is installed properly in the rack, the mounting screws on one side of the rack should align with the mounting screws on the opposite side and the router should be level. Add all remaining screws. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 109 Installing your 32-slot router in a 4-post rack or open cabinet You can install Brocade MLX Series 32-slot routers in a 4-post rack or open cabinet using the optional 4-post rack mount kit available from Brocade. The following table lists the contents of this kit.
Page 110 Attach the side rails to the front and back of the rack, using screws appropriate for your rack type. (You must provide these screws). Refer to Figure NOTE The narrow telescoping ends of the side rails should attached at the back of the rack. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 111 Use the mechanical lift to position the chassis as close to the rack as possible. Slide the chassis off the lift and onto the side rails and gently guide the chassis into the rack. Refer to Figure Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 112 Once the chassis is securely inserted in the rack, fasten the mounting ears to the front rails of the rack using screws appropriate for your rack type (eight screws per side). Refer to Figure Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 113: Installing Brocade Mlx-32 Router Modules
Interface modules running software releases below 02.3.00 should only be inserted in slots 1 to 16. • All empty slots must contain slot blanks to ensure proper air flow within the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 114 The intra-building ports of the equipment or subassembly MUST NOT be metallically connected to interfaces that connect to the outside plant (OSP) or its wiring. These interfaces Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 115 If you are installing a redundant management module, refer to the chapter titled “Using a Redundant Management Module” in the Brocade MLX Series and Brocade NetIron Family Configuration Guide for information about how the redundant module works, optional software configurations that you can perform, and how to manage the redundancy feature.
Page 116 Enter the write memory command to ensure that the slot will be correctly configured for the new module after a reboot. Brocade(config)# write memory Write startup-config done. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 117: Brocade Mlx-32 Cable Management
Figure 74 shows the cable routing, with the upper and lower cable management system covers removed for clarity. The following sections describe cable routing for each quadrant of the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 118 Always route the cables for the outer-most modules out the sides of the unit. Route the cables for the innermost modules through the top or through the bottom cable management hardware on the unit. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 119 1.5 in. for Category 5 (RJ45) and fiber-optic cables. Cable routing for the upper-left quadrant Route cabling from slots in numerical order starting with the cables for slot #1. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 120 FIGURE 76 Routing upper-left quadrant cables up Upper left quadrant Comb B (slot #5 and #6 cables) Comb C (slot #7 and #8 cables) Comb A (slot #3 and #4 cables) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 121 Route cables from slots #15 and #16 directly to the right through the side comb. Refer to Figure FIGURE 77 Routing upper-right quadrant cables to the right Upper right quadrant Cables from slot #15 Side combs (18) Cables from slot #16 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 122 Route cables from slots #13 and #14 up through comb A. Refer to Figure Route cables from slots #11 and #12 up through comb B. Route cables from slots #9 and #10 up through comb C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 123 Route cables from slots #18 and #17 directly to the left through the side comb. Refer to Figure FIGURE 79 Routing lower-left quadrant cables Lower left quadrant Cables from slot #18 Cables from slot #17 Side combs (18) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 124 Route cables from slots #20 and #19 down through comb A. Refer to Figure Route cables from slots #22 and #21 down through comb B. Route cables from slots #24 and #23 down through comb C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 125 Route cables from slots #32 and #31 directly to the right through the side comb. Refer to Figure FIGURE 81 Routing the lower-right quadrant cables Lower right quadrant Cables from slot #32 Cables from slot #31 Side combs (18) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 126: Accessing Modules For Service
This procedure is easier with two people. One person can hold the cable bundles aside while the other person loosens the connectors and removes the module. Be careful not to overtighten or cross-thread cable connector screws. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 127: Installing Power Supplies In A Brocade Mlx-32 Router
Follow these steps to install a power supply in a Brocade MLX-32 router. Remove the blank power supply faceplate. Remove the power supply from the packaging. Insert the power supply into the slot, using the guides on each side of the slot. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 128 Pull the release latch on the power supply front panel up to lock the power supply in place, and screw the retaining screw into place. Install a blank power supply faceplate into each empty slot. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 129: Connecting Ac Power
DC-to-DC power supply provides the DC power to the router at 12V and 200A. The 3000W DC-to-DC power supply provides DC power to the router at 12V and 245A. The procedure in this section is for qualified service personnel. Follow these steps to connect a DC power source: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 130 Power lug Crimp the correct AWG power supply wire into the power lugs: #4 AWG wire for 2400 W power supply #2 AWG for 3000 W power supply Refer to Figure Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 131: Removing Brocade Mlx-32 Router Dc Power Supplies
This equipment installation must meet NEC/CEC code requirements. Consult local authorities for regulations. Removing Brocade MLX-32 router DC power supplies Follow these steps to remove a 2400W DC power supply in a Brocade MLX-32 router: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 132: Final Steps
PC or terminal or through a Telnet connection. Before performing this task, you need the following items: • PC running a terminal emulation application or a terminal. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 133: Activating The Power Source
The mark is your assurance that the power cord can be used safely with the device. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 134: Verifying Proper Operation
Verify that the connection to the other router has been properly made. Also, make certain that the other router is powered on and operating correctly. • Try using a different cable. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 135 You must replace the switch fabric module. Refer to “Replacing a user packets. switch fabric module” on page 252. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 136 IN LED is green, then there is a problem with the power supply to the router. and it must be replaced. The power supply is Amber The power supply is malfunctioning. in normal operating condition. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 137: Displaying The Module Status
The Status column shows the module status. The management module status can be one of the following: • ACTIVE – The module is currently the active management module. • STANDBY – The module is currently the standby management module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 138: Forced Card Deletion
Brocade(config)#no module <slot> <module-type> Example: Brocade(config)#no module 2 ni-mlx-8-port-10g-d NOTE This is best pulled directly from the running configuration. Answer to the prompt by pressing Wait for the new module to come up. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 139 S7: NI-MLX-10Gx8-M 8-port 10GbE (M) Module CARD_STATE_UP 0024.3887.4020 S8: BR-MLX-40Gx4-M 4-port 40GbE Module CARD_STATE_UP 0024.3887.4050 Brocade#configure terminal Brocade(config)#no module 2 ni-mlx-8-port-10g-d NOTE This command pertains to the output of the command previously executed. show running-config Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 140 Brocade#show running-config | include module module 1 br-mlx-4-port-40g-m module 2 ni-mlx-8-port-10g-m module 3 ni-mlx-8-port-10g-d module 4 ni-mlx-8-port-10g-m module 5 ni-mlx-8-port-10g-m module 6 ni-mlx-20-port-1g-copper module 7 ni-mlx-8-port-10g-m module 8 br-mlx-4-port-40g-m snmp-server max-ifindex-per-module 64 Brocade# Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 141: Installing A Netiron Xmr Router
The mark is your assurance that the power cord can be used safely with the router. All fiber-optic interfaces use Class 1 Lasers. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 142 If you do not install a module in a slot, you must keep the slot blank in place. If you run the router with an uncovered slot, the system may overheat. Never leave tools inside the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 143: Power Precautions
Compare this total with the rating limit for the circuit. The maximum ampere ratings are usually printed on the devices near the input power connectors. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 144: Installing 2X100Gbe Interface Modules In Netiron Xmr Routers
2x100G modules occupy two adjacent slots. When you install a 2x100G module, the odd numbered (low number) slot of the slot pair becomes the active slot, and the even numbered slot (higher number) is blocked. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 145: Installation Procedure
Do not discard the center slot guide, as you will need it if you want to revert to a 2-slot configuration. If you misplace your center slot guide, you can purchase a replacement from Brocade. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 146 The 2x100G interface module is sensitive to dust and debris. Keep the optics covers in place until you are ready to connect the fiber cable. Clean all fiber cables properly before you connect them to the 2x100G interface module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 147: Installing A Netiron Xmr 4000 Router
FIGURE 92 Installing 2x100G modules in a 16- or 32-slot device (16-slot shown) Installing a NetIron XMR 4000 router The following sections describe how to install a NetIron XMR 4000 router: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 148: Preparing The Installation Site
You must remove these screws before installing the router. Figure 93 shows the location of the screws. To perform this task, you need a #2 Phillips-head screwdriver. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 149 Mount the lowest router in the rack as shown in Figure 95. Slip the wide portion of each keyhole slot over the corresponding mounting screw in the rack. Two people may be required to perform this task. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 150: Installing Netiron Xmr 4000 Modules
MUST NOT be metallically connected to interfaces that connect to the outside plant (OSP) or its wiring. These interfaces are designed for use as intra-building interfaces only (Type 2 or Type 4 ports Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 151 Switch fabric modules SF1 – SF3 If you are installing a redundant management module, refer to the Brocade MLX Series and Brocade NetIron Family Configuration Guide for information about how the redundant module works, optional software configurations, and how to manage redundancy.
Page 152 25) and slide the card along the card guide until the ejectors on either side of the module rotate towards the module faceplate. FIGURE 96 Installing a module in the NetIron XMR router Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 153: Installing Netiron Xmr 4000 Router Power Supplies
Carefully follow the mechanical guides on each side of the power supply slot and make sure the power supply is properly inserted in the guides. Never insert the power supply upside down. FIGURE 97 Installing a power supply in a NetIron XMR router Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 154 Lift the cord retainer and connect an AC power cord to the power supply. Snap the cord retainer over the power plug to hold it in place. FIGURE 98 Connecting a power cord to the power supply in a NetIron XMR 4000 router Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 155 Use a #2 Phillips screwdriver to remove the power lugs, as shown in Figure Crimp #8 AWG power supply wire into the power lugs and reconnect the lugs to the power supply unit. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 156: Final Steps
“Attaching a management station” • “Activating the power source” • “Verifying proper operation” Installing a NetIron XMR 8000 router The following sections describe how to install a NetIron XMR 8000 router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 157: Preparing The Installation Site
You must remove these screws before installing the router. Figure 101 shows the location of the screws. To perform this task, you need a #2 Phillips screwdriver. FIGURE 101 Shipping screw locations Router front Router back Shipping screws Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 158: Installing The Netiron Xmr 8000 Router In A Rack
Position two of the four mounting screws for each router according to the spacings of the keyhole slots on the mounting brackets, as shown in Figure 102. When tightening the screws leave approximately 1/4 inch clearance between the back of the screw head and the rack post. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 159 Standard 19-inch rack Mounting screws Slide the router down so that the screw heads are in the narrow portion of the keyhole slots. Tighten the screws to secure the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 160: Installing Netiron Xmr 8000 Modules
The NetIron XMR 8000 router ships with slot blanks installed in all empty module slots. The slot blanks cover empty slots, ensuring proper airflow within the router. Before you install a module in a slot, you must remove the slot blank. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 161 Pull the slot blank out of the router, and store it in a safe place for future use. NOTE If you are installing a redundant management module, refer to Brocade MLX Series and Brocade NetIron Family Configuration Guide for information about how the redundant module works, optional software configurations, and how to manage redundancy.
Page 162: Installing Netiron Xmr 8000 Router Power Supplies
Carefully follow the mechanical guides on each side of the power supply slot and make sure the power supply is properly inserted in the guides. Never insert the power supply upside down. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 163 Lift the cord retainer and connect an AC power cord to the power supply. Snap the cord retainer over the power plug to hold it in place. FIGURE 106 Connecting a power cord to the power receptacle Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 164 Follow these steps to connect a DC power source. Use a #1 Phillips screwdriver to remove the two screws that hold the transparent cover over the power supply lugs, as shown in Figure 107. Remove the transparent cover. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 165 To ensure adequate bonding when attaching the ground lug, a minimum of 20 PSI of torque is required to be applied to the mounting hardware used to attach the ground lug. FIGURE 108 Crimping the power supply wire in the lug Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 166: Final Steps
Remove the router from the shipping carton and all packing materials. Save the shipping carton and packing materials in case you need to move or ship the router at a later time. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 167: Installing A Netiron Xmr 16000 Router In A Rack
You must provide four standard #12-24 pan-head screws for each NetIron XMR 16000 router that you install in a rack. To perform this task, you will need a #2 Phillips screwdriver. Follow these steps to mount a NetIron XMR 16000 router in a rack. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 168 Mount in the router that will have the lowest position in the rack first, as shown in Figure 110. With two or more people lifting the router, slip the wide portion of each keyhole slot over the corresponding screw in the rack. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 169: Installing Netiron Xmr 16000 Modules
MUST NOT be metallically connected to interfaces that connect to the outside plant (OSP) or its wiring. These interfaces are designed for use as intra-building interfaces only (Type 2 or Type 4 ports Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 170 Install a management module in management slot 2. • Install interface modules in interface slots 2, 4, 6, and 8. • Install switch fabric modules in the switch fabric slots 2 and 4. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 171 Install interface modules in interface slots 9,11,13, and 15. NOTE If you are installing a redundant management module, refer to the Brocade MLX Series and Brocade NetIron Family Configuration Guide for information about how the redundant module works, optional software configurations that you can perform, and how to manage the redundancy feature.
Page 172: Installing Power Supplies In A Netiron Xmr 16000 Router
Remove the power supply slot blank. Remove the power supply from the packaging. Insert the power supply into the slot, using the guides on each side of the slot. Refer to Table 112. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 173 Connecting AC power AC power is supplied through a power cord connected to the power supply installed in the NetIron XMR 16000 router. Follow these steps to connect the AC power source. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 174 Snap the cord retainer over the power plug to hold it in place. FIGURE 113 Connecting a power cord to the power supply in a NetIron XMR 16000 router Lift handle Power cord Lift handles Cord retainer Ground point Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 175 6 American Wire Gauge (AWG). The ground wire should have an agency-approved crimped connector (provided with the device) attached to one end, with the other end Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 176: Final Steps
“Attaching a management station” • “Activating the power source” • “Verifying proper operation” Installing a NetIron XMR 32000 router This section describes how to install a NetIron XMR 32000 router: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 177: Preparing The Installation Site
Use a power drill with Phillips and large flat-blade screwdriver attachments to remove the bolts and screws that hold the front shipping panel in place, as shown in Figure 116. Remove the front shipping panel and set it aside. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 178: Installing A Netiron Xmr 32000 Router In A Rack
Because of the weight of a fully loaded NetIron XMR 32000 router, it is recommended that you mount the router in a rack before installing the modules and AC power supplies. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 179 Use a mechanical lift equipped with a lift plate. Position the lift plate as close to the front of the router as possible. Adjust the lift plate height to be even with the bottom of the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 180: Installing Netiron Xmr 32000 Modules
When populating the NetIron XMR 32000 router, the modules must be installed in the appropriate slots: • Management modules: management slots 1 and 2 • Switch fabric modules: switch fabric slots 1-8 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 181 Hardware Installation Notes that shipped with the management module. If you are installing a redundant management module, refer to the Brocade MLX Series and Brocade NetIron Family Configuration Guide for information about how the redundant module works, optional software configurations, and how to manage redundancy.
Page 182 Due to the high density of cables that the NetIron XMR 32000 router can support, it may be difficult to insert and remove the RJ45 and optical connectors. An insertion or extraction tool has been provided in the NetIron XMR 32000 accessory kit to make this task easier. Refer to Figure 119. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 183: Netiron Xmr 32000 Cable Management
Always route the cables for the outer-most modules out the sides of the unit. Route the cables for the innermost modules through the top or through the bottom cable management hardware on the unit. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 184 1.5 in. for Category 5 (RJ45) and fiber-optic cables. Cable routing for the upper-left quadrant Route cabling from slots in numerical order starting with the cables for slot #1. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 185 Route cables for slots #1 and #2 directly to the left through the side comb. Refer to Figure 121. FIGURE 121 Routing upper-left quadrant cables Upper left quadrant Cables from slot #1 Side combs (18) Cables from slot #2 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 186 Route cables from slots #3 and #4 up through comb A. Refer to Figure 122. Route cables from slots #5 and #6 up through comb B. Route cables from slots #7 and #8 up through comb C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 187 Route cables from slots #15 and #16 directly to the right through the side comb. Refer to Figure 123. FIGURE 123 Routing Upper-right quadrant cables to the right Upper right quadrant Cables from slot #15 Side combs (18) Cables from slot #16 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 188 Route cables from slots #13 and #14 up through comb A. Refer to Figure 124. Route cables from slots #11 and #12 up through comb B. Route cables from slots #9 and #10 up through comb C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 189 Route cables from slots #18 and #17 directly to the left through the side comb. Refer to Figure 125. FIGURE 125 Routing lower-left quadrant cables Lower left quadrant Cables from slot #18 Cables from slot #17 Side combs (18) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 190 Route cables from slots #20 and #19 down through comb A. Refer to Figure 126. Route cables from slots #22 and #21 down through comb B. Route cables from slots #24 and #23 down through comb C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 191 Route cables from slots #32 and #31 directly to the right through the side comb. Refer to Figure 127. FIGURE 127 Routing the lower-right quadrant cables Lower right quadrant Cables from slot #32 Cables from slot #31 Side combs (18) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 192: Accessing Modules For Service
This procedure is easier with two people. One person can hold the cable bundles aside while the other person loosens the connectors and removes the module. Be careful not to overtighten or cross-thread cable connector screws. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 193: Installing Netiron Xmr 32000 Router Power Supplies
Remove the power supply slot blank. Remove the power supply from the packaging. Insert the power supply into the empty power supply slot, using the guides provided on either side of the slot. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 194 After the power supply is fully inserted, push the power supply front panel toward the back of the router. This action causes the power supply connector to seat into the backplane connector. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 195 12 V and 200 A. The 3000 W DC-to-DC supply provides the DC power to the router at 12V and 245A. The procedure in this section is for qualified service personnel. Follow these steps to connect a DC power source. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 196 Power lug (2) Crimp the correct AWG wire into the power lugs: For 2400 W power supply, crimp #4 AWG For 3000 W power supply, crimp #2 AWG. Refer to Figure 134. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 197 Connect the wire to your DC power source, making sure to connect the -48V cable to the negative terminal on the power supply and the 0V cable to the positive terminal as marked on the power supply. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 198: Removing Netiron Xmr 32000 Router Dc Power Supplies
The management network that you connect to through the 10/100 Ethernet port must be separate and isolated from the network over which user packets are switched and routed. For information about functionality on the management port, Refer to “Understanding management port functions” on page 206. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 199: Attaching A Pc Or Terminal To The Console Port Or To The Ethernet Port
DB-9 or DB-25 connector, depending on the specifications of your PC or terminal. You can order this cable from Brocade Communications Systems, Inc. or build your own cable. If you build your own cable, refer to the pinout information in “Console port pin assignments”...
Page 200: Verifying Proper Operation
Verify that the connection to the other router has been port. properly made. Also, make certain that the other router is powered on and operating correctly. • Try using a different cable. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 201 • If you are using AC power supplies, refer to the AC power supply LED information in this table for more information. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 202 CLI prompt to determine if a power supply has failed. If a power supply has failed, you must replace it. • If the LED is amber, you must replace the fan module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 203: Displaying The Module Status
CARD_STATE_LP_SYNC – The software images are synchronized between the management module and interface module. • CARD_STATE_SYNC – The system is currently synchronizing the software image between the management module and interface module. • CARD_STATE_SOFTWARE_LOADED – The module has loaded the software image. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 204: Forced Card Deletion
S4: NI-MLX-10Gx8-M 8-port 10GbE (M) Module CARD_STATE_UP 0024.3887.3f90 S5: NI-MLX-10Gx8-M 8-port 10GbE (M) Module CARD_STATE_UP 0024.3887.3fc0 S6: NI-MLX-1Gx20-GC 20-port 10/100/1000 Copper Module CARD_STATE_UP 0024.3887.3ff0 S7: NI-MLX-10Gx8-M 8-port 10GbE (M) Module CARD_STATE_UP 0024.3887.4020 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 205 S5: NI-MLX-10Gx8-M 8-port 10GbE (M) Module CARD_STATE_UP 0024.3887.3fc0 S6: NI-MLX-1Gx20-GC 20-port 10/100/1000 Copper Module CARD_STATE_UP 0024.3887.3ff0 S7: NI-MLX-10Gx8-M 8-port 10GbE (M) Module CARD_STATE_UP 0024.3887.4020 S8: BR-MLX-40Gx4-M 4-port 40GbE Module CARD_STATE_UP 0024.3887.4050 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 206 Brocade#show running-config | include module module 1 br-mlx-4-port-40g-m module 2 ni-mlx-8-port-10g-m module 3 ni-mlx-8-port-10g-d module 4 ni-mlx-8-port-10g-m module 5 ni-mlx-8-port-10g-m module 6 ni-mlx-20-port-1g-copper module 7 ni-mlx-8-port-10g-m module 8 br-mlx-4-port-40g-m snmp-server max-ifindex-per-module 64 Brocade# Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 207: Cable Cinch Overview
Velcro strap around the cable cinch. Use the additional slots in the clip to secure groups of cables as required. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 208: Cable Cinch With Two Mrj21 Cables
To secure two mRJ21 cables, place the Velcro strap through slot one and use the front and rear left recesses as shown in Figure 137. FIGURE 137 Two mRJ21 cables Cable cinch with three mRJ21 cables Three mRJ21 cables may be secured as shown in Figure 138. FIGURE 138 Three mRJ21 cables Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 209: Cable Cinch With Four Mrj21 Cables
Four mRJ21 cables may be secured as shown in Figure 139. FIGURE 139 Four mRJ21 cables Cable cinch with five mRJ21 cables Five mRJ21 cables may be secured as shown in Figure 140. FIGURE 140 Five mRJ21 cables Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 210: Cable Cinch With Six Mrj21 Cables
Six mRJ21 cables may be secured as shown in Figure 141. FIGURE 141 Six mRJ21 cables Cable cinch with seven mRJ21 cables Seven mRJ21 cables may be secured as shown in Figure 142. FIGURE 142 Seven mRJ21 cables Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 211: Cable Cinch With Eight Mrj21 Cables
RJ45 cables may be secured in groups of six. To secure up to six RJ45 cables in one group, place the Velcro strap through slot one and use the front left recesses as shown in Figure 144. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 212: Cable Cinch With Two Groups Of Rj45 Cables
FIGURE 145 12 RJ45 cables in two groups Cable cinch with three groups of RJ45 cables 18 RJ45 cables, in three groups, may be secured as shown in Figure 146. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 213: Cable Cinch With Four Groups Of Rj45 Cables
Cable cinch with four groups of RJ45 cables 24 RJ45 cables, in four groups, may be secured as shown in Figure 147. FIGURE 147 24 RJ45 cables in four groups Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 214: Cable Cinch With Five Groups Of Rj45 Cables
Cable cinch with six groups of RJ45 cables 36 RJ45 cables, in six groups, may be secured as shown in Figure 149. FIGURE 149 36 RJ45 cables in six groups Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 215: Cable Cinch With Seven Groups Of Rj45 Cables
Cable cinch with eight groups of RJ45 cables 48 RJ45 cables, in eight groups, may be secured as shown in Figure 151. FIGURE 151 48 RJ45 cables in eight groups Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 216 RJ45 procedures Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 217: Connecting A Router To A Network Device
Access the CONFIG level of the CLI by entering the configure terminal command. Brocade# configure terminal Brocade(config)# Syntax: configure terminal Enter the enable super-user-password command to set the super-user password. Brocade(config)# enable super-user-password mustang Syntax: enable super-user password <text> Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 218: Configuring Ip Addresses
Instead of assigning a global IP address to the router for system management purposes, you must assign an IP address to the active management module. If the active management module becomes unavailable and the redundant module becomes the active module, the IP address is automatically assigned to the new active management module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 219: Assigning Ip Addresses To An Interface, Virtual Interface
By default, you can configure up to 24 IP addresses on each interface, virtual interface, and loopback interface. For example, to assign the IP address 192.22.3.44 and subnet mask 255.255.255.0 to Ethernet interface 1/1, do the following. At the opening CLI prompt, enter enable. Brocade# enable Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 220: Enabling And Disabling The Interfaces
The management port performs specific functions and is subject to some limitations, as described: • Because the management port allows you to configure, monitor, and manage routers only, this port has the same limited functionality as an IP host port. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 221: Connecting The Router To A Network Device
CLI level. Connecting the router to a network device You can connect a router to another Ethernet network device. Brocade MLX Series and NetIron XMR routers support connections to other vendors’ devices as well as Brocade network devices. The Ethernet interface modules available with Brocade MLX Series and NetIron XMR routers are described in “Interface modules”...
Page 222: Cabling A Fiber-Optic Transceiver
To clean the fiber-optic ports and cable connectors, it is recommended that you use a fiber-optic reel-type cleaner. You can purchase this type of cleaner from the following website: http://www.fisfiber.com/ When you are not using a fiber-optic transceiver port, always replace the protective cover. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 223: Troubleshooting Network Connections
Syntax: ping <ip addr> | <hostname> [source <ip addr>] [count <num>] [timeout <msec>] [ttl <num>] [size <byte>] [quiet] [numeric] [no-fragment] [verify] [data <1-to-4 byte hex>] [brief] Beginning with version 03.6.00 of the Multi-Service IronWare software, the maximum allowable size is 9170 bytes. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 224: Tracing A Route
The CLI displays traceroute information for each hop on the route as soon as the information is received. Traceroute requests display all responses to a given TTL. If there are multiple equal-cost routes to the destination, the router displays up to three responses by default. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 225: Managing Routers And Modules
You can specify 1-4 for 4-slot routers, 1-8 for 8-slot routers, 1-16 for 16-slot routers, and 1-32 for 32-slot routers. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 226: Monitoring I2C Failures On Management Modules
0-1 - there are total of 2 MUX indexes in NetIron XMR 32000 and Brocade MLX-32 devices. The MUX index is always zero in 4-, 8-, and 16-slot NetIron XMR or Brocade MLX devices Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 227 Static Log Buffer: Apr 16 18:21:25:A:System: Power Supply 2 , middle, Not Installed (FAILED) Apr 16 18:21:25:A:System: Power Supply 3 , top, Not Installed (FAILED) Dynamic Log Buffer (50 lines): Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 228: Displaying Device Status And Temperature Readings
Slot1 pri=1 module type=NI-MLX-1Gx20-GC 20-port 10/100/1000 Copper Module power usage=156W Slot4 pri=1 module type=NI-X-OC48x8 8-port OC48/12 STM16/STM4 Module power usage=230W --- FANS --- right fan tray (fan 1): Status = OK, Speed = MED-HI (90%) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 229 The total power budget for the device minus the total power used by the system core and the installed interface modules. Slot Power-On Priority The configured power-on priority of each interface module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 230: Displaying The Syslog Configuration And Static And Dynamic Buffers
A=alert C=critical D=debugging M=emergency E=error I=informational N=notification W=warning Syntax: show logging The following table describes the Syslog output buffer configuration information, in the rows above the log entries. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 231 When you clear log entries, you can selectively clear the either buffer, or you can clear both. For example, to clear only the dynamic buffer, enter the clear logging command at the Privileged EXEC level. Brocade# clear logging dynamic-buffer Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 232: Mp Presence From Lp Detection (Headless Router Operation)
MP_SWITCH MP_SDS_CON MP_WAIT MP_ALIVE_DISABLED MP presence is toggled when you enter the ipc toggle mp-presence command. Active MP presence is displayed for the LP as shown in the following table. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 233: Rolling Reboot
The Rolling Reboot feature places the line card into the interactive or down state mode on detection of an FPGA version mismatch. This feature will detect the incompatibility between application FPGA version and Hardware FPGA version and put the card into down state if there is mismatch. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 234: Line Module Configuration Deletion In Interactive Boot Mode
The system blocks discovery of any standard switch fabric (G1) module if you have issued the system-init block-g1-sfm command. Refer to “Blocking discovery of G1 switch fabric modules” on page 221. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 235: Forcing Hsf Modules To Operate In Normal Mode
Auto control of fan speed is not monitored when cards are in interactive mode. Set fan speed to high to prevent over-temp condition. NOTE Adjusting fan controls out of the default setting can negatively affect the efficient cooling of blades and may cause a blade to overheat and shutdown. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 236 Low temperature threshold High temperature threshold Management modules High 77 C 85C Medium-high 67C 80C Medium 57C 70C –1 60C Management modules CPU High 75 C 95C Medium-high 65C 80C Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 237 Interface modules Packet Processor* High 95 C (70 C) 113 C (113C) Medium-high 85 C (60C) 100 C (75C) Medium 50 C (45 C) 90 C (65 C) –1 80 C (50C) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 238 – Changes low and high temperature thresholds for Gen 1 interface modules • lp2 – Changes low and high temperature thresholds for Gen 2 interface modules • mp – Changes low and high temperature thresholds for management modules Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 239 = 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 === Thermal Sensor Control Block (THERMAL_SENSOR_TEST_RULE_LP_XPP) === Fan Speed Low: -1 - 50 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 240 When syslog messages display a change in fan speed, you can identify which sensors triggered the change by checking show chassis and show fan-threshold command output and looking for sensors with temperatures near threshold boundaries.Table 39 lists the associations between the show chassis, show fan-threshold, and fan-threshold commands. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 241 LP2 Sensor 7 reading UNUSED UNUSED BR-MLX-100Gx2-X LP Modules LP2 Sensor 1 reading THERMAL_SENSOR_TEST_RULE_LP_2 fan-threshold lp2 LP2 Sensor 2 reading THERMAL_SENSOR_TEST_RULE_LP_XPP N/A (Must not be changed) LP2 Sensor 3 reading UNUSED UNUSED Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 242: Manually Setting The Fan Speed
Setting a value other than auto or high disables auto fan control and will negatively affect the efficient cooling of blades and may cause a blade to overheat and shutdown. For example, to set the speed of fan 0 to medium-high, enter the following command. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 243: Monitoring The Cooling System
222.) This section describes how to view the system log. If you have configured your router to use a Syslog server or SNMP trap receiver, refer to the documentation for the server or receiver. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 244: Temperature Log Reduction
Interface modules boot from a source specified by the management module (the default source is a primary image in the flash memory on the interface module.) You can make these changes: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 245 Privileged EXEC level. Brocade# lp sync all Syntax: lp sync [all | <slot-number>] • The all keyword indicates that the immediate synchronization applies to all interface modules in the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 246 To specify an immediate boot for the interface module installed in slot 1 from the auxiliary flash slot on the management module, enter the lp boot system command at the Privileged EXEC level of the CLI. Brocade# lp boot system slot1 primary 1 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 247 The slot-number parameter specifies the slot number that contains the interface module that will undergo an immediate boot. You can specify 1 – 4 for 4-slot devices, 1 – 8 for 8-slot devices, 1 – 16 for 16-slot devices, or 1 – 32 for 32-slot devices. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 248 Configuring an automatic boot from a TFTP server To configure an automatic boot for all interface modules from a TFTP server, enter the following command at the global CONFIG level of the CLI. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 249: Changing Priority Of Slots For Interface Modules
1, enter the following command at the Privileged EXEC level of the CLI. Brocade# power-off lp 1 To disable power on all interface modules, enter the following command: Brocade# power-off lp all Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 250: Monitoring Link Status
This feature is included by default in NetIron R05.3.00 and later; no configuration is required to enable it. Disabling monitoring link status To disable the link status monitoring feature, enter the following command: no system-monitoring tm port-control Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 251: Displaying Fabric Link Status (Fix For Html)
Syslog messages The following syslog messages are related to link monitoring: • System: Interface Ethernet 3/1, state down -fabric connectivity down • System: Interface Ethernet 3/1, state up –fabric connectivity up Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 252: Using Alarms To Collect And Monitor Device Status
To reset the alarm history back to the default buffer size, use the alarm history command with the no operand. For example, to set the buffer size back to the default entry size from 100, enter the following command: Brocade# no alarm history 100 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 253: Configuring Alarm Logging
To display all alarms on the system of all alarm levels (as per your configured alarm severity logging), enter the following command: Brocade# show alarm all 3 15:01:44 | Major | Chassis | Power-Supply 2 - Not Present Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 254 (where x, is the temperature device number). To display all alarms in the alarm log for all interface show alarm [history] lp all modules and subsystems for the management module. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 255 Alarms and warnings are monitored only for optic devices that support optical monitoring. If optical monitoring is disabled, then no alarms are generated. If an optic is removed or not present, a major alarm is reported and logged and any existing alarms are cleared from the current alarm log. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 256: Clearing The Alarm History Log
Brocade# show mem Memory Used Available Success Hold Fail Error 0 21401600 14397440 1508 1 51474432 216961024 Shared 2 107184128 2747834368 25969 10813 Global 267386880 User Private Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 257: Enabling And Disabling Management Module Cpu Usage Calculations
Use the show cpu command to display usage averages for all tasks performed by the management module as shown in this example. Brocade# show cpu ... Usage average for all tasks in the last 1 seconds ... ========================================================== Name us/sec idle 755423 monitor flash boot main ip_rx Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 258: Displaying Management Module Cpu Usage
31 susp 0000c658 0409af80 8192 boot 17 susp 0000c658 041dbe30 65536 main 3 susp 0000c658 2060cf38 65536 itc 6 susp 0000c658 20610af0 16384 tmr 5 susp 0000c658 206a7638 16384 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 259: Removing Mac Address Entries
Use the module slot-num parameter to remove all MAC addresses for an interface module in a specified device slot. • Use the vlan number parameter to remove all MAC addresses for a specified VLAN. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 260: Simplified Upgrade
2) Installed /XMR-MLX/Boot/InterfaceModule/xmlprm05600.bin to LP Boot on all LP slots 3) Installed /XMR-MLX/Monitor/ManagementModule/xmb05600.bin to MP Monitor 4) Installed /XMR-MLX/Monitor/InterfaceModule/xmlb05600.bin to LP Monitor on all LP slots 5) Installed /XMR-MLX/Application/ManagementModule/xmr05600b296.bin to MP Primar Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 261: Single-Command Package Upgrade
In a full-system upgrade where an external set of images (or, release package) is to be applied to the system, it makes sense to perform a version comparison between what is currently running in the system and the release package (while LP Auto-Upgrade compares the image version in LP and that of the system). Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 262 Simplified Upgrade Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 263: Maintenance And Field Replacement
If you install these modules in another Brocade device or you install a module intended for another Brocade device in a Brocade router, the device and modules will not function properly. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 264: Replacing A Management Module
Put the screws and cover plate aside; you will need to reattach the cover using the screws after installing the card. Slide the compact flash card into the slot. Reattach the cover plate using the two screws and screwdriver. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 265: Replacing An Interface Module
Removing and replacing an interface module To remove or replace an interface module, see the module instructions in the installation chapter that is appropriate for your router model. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 266: Replacing A Switch Fabric Module
If you need to remove all of the switch fabric modules at the same time, you must shut down the router and remove the power source. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 267: Replacing A Fiber-Optic Transceiver
Replacing a power supply You can replace a power supply while the device is powered on and running. For the location of the power supplies (AC or DC) refer to “Product Overview”. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 268: Determining Which Power Supply Failed
NOTE A threshold value of 0 will not automatically shutdown a power supply due to failures. For Syslog messages, please refer to Appendix A, Using Syslog in the Brocade MLX Series and Brocade NetIron Family Configuration Guide. Clearing power supply failure timestamps Use the power-supply monitoring clear command to clear all collected failure timestamps for a given power supply, or for all available power supplies.
Page 269: Displaying Power Supply Monitoring Timestamps
You can also use the show running-config command to display the power supply monitoring threshold configuration, as displayed in the following example. Brocade#show running-config Current configuration: ver V5.4.0T163 module 1 br-mlx-2-port-100g-x Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 270: Enabling A Power Supply Shutdown
ERROR: Power Supply # 3 is the Last Available in the system and will not be shutdown. To force the shutdown, please use keyword "forced" Syntax: power-off power-supply [forced] <decimal> The power-supply keyword allows you to shut down a power supply. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 271: Powering On The Power Supply Through The Cli
The decimal variable specifies a power supply index number. Replacing a power supply To replace a power supply, have the following items available: • A new power supply (AC or DC), which you can order from Brocade Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 272 Pull the handle straight out toward you to unlock the power supply (see Figure 155). Pull the power supply out of the device. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 273 For a 4-slot device only, use the screwdriver to secure the two screws on either side of the power supply faceplate. For a 2400W DC power supply only, crimp the #4 AWG power supply wire in the power lugs. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 274: Replacing Fan Assemblies
LED on the fan assembly being replaced to turn green before replacing another fan assembly. Do not remove all fans from the device at once. Before replacing a fan assembly, have the following items available: • A new fan assembly, which you can order from Brocade Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 275 The 32-slot router fan assembly is heavy and will be off-balance as you remove it. Use both hands on the handle. Be careful not to insert your fingers into the fan while removing it from the device. The fan may still be spinning at a high speed. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 276 Secure the fan assembly to the router by replacing and tightening the four screws (on the upper eight fan assemblies) and the two screws (on the lower two fan assemblies). Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 277: Replacing Fan Assemblies In 16-Slot Routers
157. Pulling the fan assembly unseats the fan connector from the router connector. Be careful not to insert your fingers into the fan while removing it. The fan may still be spinning at a high speed. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 278 Be careful not to accidently insert your fingers into the fan while removing it. The fan may still be spinning at a high speed. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 279: Replacing The Fan Tray Assembly In 4-Slot And 8-Slot Routers
You will need to remove the router from the rack to remove the shipping screws, (refer to the installation chapter appropriate for your router model) before you can remove the fan tray assembly. Follow these steps to replace fan tray assemblies in 4-slot routers. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 280 Be careful not to insert your fingers into the fan while removing it. The fan may still be spinning at a high speed. FIGURE 159 Replacing a fan tray assembly in a Brocade MLX or NetIron XMR 4-slot router. Latch release Fan tray assembly Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 281 Tighten the four captive screws to secure the fan to the router. Access the CLI, and enter the show chassis command to verify that the fans are operating normally. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 282: Replacing The Air Filters
Remove the old air filter by pulling it straight out from the router, as shown in Figure 163. Insert a new filter, being careful that it aligns within the narrow channel. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 283 Follow these steps to replace the air filter in a Brocade MLX or NetIron XMR 16-slot router. Loosen the two screws in the front of the filter retainer. Pull the filter retainer away from the router as shown in Figure 164. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 284 Follow these steps to replace the air filter in 4-slot and 8-slot routers. Loosen the two screws in the front of the filter retainer. Pull the filter retainer away from the router as shown in Figure 165 Figure 166. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 285 The filter is marked with an arrow that indicates how the filter should be installed for proper airflow in the device. Since air is pulled through the router, the arrow must point right towards the fan tray. Push the filter retainer into the router and tighten the two screws. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 286: Installing Upward Deflectors On Fan Assemblies
Hazardous energy levels exist at these locations. Remove the fan assembly by grasping the handle on the faceplate and pulling the fan assembly toward you. Pulling the fan assembly unseats the fan connector from the router. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 287 If louvers are present inside the fan assembly faceplate, detach them by removing the 11 roll pins that secure the louvers to the inside of the fan assembly faceplate. NOTE Legacy Brocade MLX-32 fan assemblies may have louvers. Louvers are not present in newer Brocade MLX-32 fan assemblies. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 288 Orient the upward deflector on the fan assembly faceplate so that the exhaust will flow upward and the holes in the upward deflector align with the holes where the screws secure the handle to the fan assembly faceplate. Refer to Figure 170 in step 4. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 289 Check the fan status LED in the lower left corner of the faceplate. It will glow red momentarily when power is applied, and then it will change to green when the fan comes up to speed. To verify that the fan is operating correctly, access the CLI and enter the show chassis command. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 290 Replacing fan assemblies Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 291: Hardware Specifications
MLX routers with 8x10G interface modules only MLX-4 1389 4740 1389 4740 1389 4740 MLX-8 2760 9419 2760 9419 2760 9419 MLX-16 5591 19081 5591 19081 5591 19081 MLX-32 11391 38876 11391 38876 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 292 2-port 10 Gbps Ethernet interface module with fiber-optic transceivers 150W 4-port 10 Gbps Ethernet interface module with fiber-optic transceivers 225W 8-port 10 Gbps Gen 2 Ethernet interface module (M) 248W 4-port 10 Gbps Ethernet interface module (X) 240W Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 293: Physical Dimensions
4.166 cm 18.796 cm 40.64 cm 4 kg (1.46 in.) (7.40 in.) (16.0 in.) (9.85 lbs) Operating environment The following table provides the operating environment specifications for Brocade MLX routers. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 294: Storage Environment
AC Input Rating: 100 to 240V, 50/60 Hz, 16.0 A maximum per power supply • AC Operating Voltage Range: 90 - 264V, 50/60 Hz • Inrush current: 40A peak maximum at 25 degrees C (77 degrees F) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 295 MR2 management module (BR-MLX-MR-X for NetIron XMR 4000, 8000 and 16000) MR2 management module (BR-MLX-32-MR2-X for NetIron XMR 32000) Switch fabric modules NI-X-SF1 switch fabric module (NetIron XMR 4000, 8000, and 16000) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 296: Physical Dimensions
44.32 cm (17.45 in.) 57.15 cm (22.5 in.) 35 kg (78 lbs) NetIron XMR 8000 31.01 cm (12.21 in.) 44.32 cm (17.45 in.) 57.15 cm (22.5 in.) 60 kg (131 lbs) Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 297: Operating Environment
EN 55024 (CE mark) (Immunity) for Information Technology Equipment • ICES-003 (Canada) (Class A) • AS/NZ 55022 (Australia) (Class A) • VCCI (Japan) (Class A) • EN 61000-3-2 • EN 61000-3-3 • EN 61000-6-1 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 298: Port Specifications For All Router Models
FIGURE 173 Console port pin assignments with connection options to a terminal or PC DB-9 to DB-9 DB-9 to DB-25 Terminal or PC Terminal or PC Female Switch Female Switch Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 299: Management Port Pin Assignments
5-15P 5-20P L6-20 “Schuko” 20A. 3-wire, 125V for 125V. 16A 220 - 250V MLXe/MLX 4, 8, 16-slot MLXe/MLX devices 4, 8, 16-slot devices Argentina Australia Austria Bahrain Belgium Brazil Canada Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 300 England Finland France Germany Greece Hong Kong Hungary India Indonesia Ireland, North Ireland, South Israel Italy Japan Korea, South Malaysia Alternate Recommended Mexico Monaco Netherlands New Zealand Norway Poland Portugal Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 301: Regulatory Compliance (Emc)
Brocade technical support. Regulatory compliance (EMC) • FCC Part 15, Subpart B (Class A) • EN 55022 (CE mark) (Class A) • EN 55024 (CE mark) (Immunity) for Information Technology Equipment Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 302: Regulatory Compliance (Safety)
30/2011/TT-BCT - Vietnam circular. • SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China). Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 303: Regulatory Statements
Machine noise information regulation - 3. GPSGV, the highest sound pressure level value is 87.4 dB(A) in accordance with EN ISO 7779. Maschinenlärminformations-Verordnung - 3. GPSGV, der höchste Schalldruckpegel beträgt 87.4 dB(A) gemäss EN ISO 7779. For Brocade MLXe-4 routers: Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 304: Japan
English translation of above statement ATTENTION: Never use the power cord packed with your equipment for other products. China The following statement applies to Brocade MLX Series and NetIron XMR devices. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 305: Taiwan
Class A device (Broadcasting Communication Device for Office Use): This device obtained EMC registration for office use (Class A), and may be used in places other than home. Sellers and/or users need to take note of this. Russia Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 306: Brazil
BI-RX-16. The Brocade MLX-32 and NetIron XMR 32000 are identified by model number BI-RX-32. 2024C Model number Certificate number BI-RX-08 1786-09-5661 BI-RX-16 1784-09-5661 BI-RX-04 1785-09-5661 BI-RX-32 1787-09-5661 Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 307: Caution And Danger Notices
Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 308 P/N LCD6-10A, y dos tornillos 1/2, PPH, 10-32 para fijar el conector rizado al chasis. La posición de conexión a tierra está situada en el lateral del chasis junto al símbolo de tierra. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 309 El cableado de entrada para la conexión al producto deberá ser de cable de cobre catalogado, 4 AWG, marcado con VW-1, y tener una capacidad nominal mínima para 90°C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 310 El cableado de entrada para la conexión al producto deberá ser de cable de cobre catalogado, 8 AWG, marcado con VW-1, y tener una capacidad nominal mínima para 90°C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 311 El cableado de entrada para la conexión al producto deberá ser de cable de cobre catalogado, 4 AWG, marcado con VW-1, y tener una capacidad nominal mínima para 90°C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 312 Si esto ocurriera, podría ser necesario que vuelva a formatear la tarjeta flash para hacer que vuelva sea utilizable. Cuando se formatea la tarjeta se borran todos los datos almacenados en la tarjeta. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 313 Le reformatage de la carte mémoire efface tous les fichiers qui s'y trouvent. PRECAUCIÓN Verifique que la tarjeta flash esté vacía o que no contenga archivos que desee conservar. Al formatear una tarjeta flash todos los archivos de ésta se borran. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 314 El desmontaje de los módulos del ventilador trasero del sistema NetIron XMR 32000 permite el acceso a las barras del bus y a la placa posterior. Evite el contacto con estas piezas. Hay niveles peligrosos de energía en tales lugares. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 315 Apriete los tornillos que fijan las cubiertas de las ranuras para impedir que se muevan al desmontar los paneles o módulos adyacentes. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 316 PRECAUCIÓN Asegúrese de no exceder el radio de curvatura recomendado para los cables: 2" para los cables MRJ-21 y 1,5" para cables de Categoría 5 (RJ45) y de fibra óptica. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 317 El cable de la conexión al producto debe ser de cobre, de calibre 12 AWG, marcado como VW-1 y como mínimo de 90 C. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 318: Dangers
L'installation et la dépose de l'unité doivent être confiées uniquement à du personnel qualifié. PELIGRO La instalación y desinstalación de la unidad debe llevarse a cabo solamente por personal cualificado. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 319 Verifique que circuitos de la fuente de corriente están conectados a tierra correctamente; luego use el cordón de potencia suministrado con el instrumento para conectarlo a la fuente de corriente. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 320 Pour des raisons de sécurité, la dragonne ESD doit contenir une résistance de série 1 méga ohm. PELIGRO Por razones de seguridad, la correa de muñeca ESD deberá contener un resistor en serie de 1 mega ohmio. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 321 El mango es un mecanismo de bloqueo solamente y no deberá usarse para alzar ni transportar el suministro de corriente. De hacerlo así, podría sufrir daños personales. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 322 REQUIEREN DOS O MÁS PERSONAS CUANDO SE VAYA A ALZAR, MANEJAR O MONTAR ESTE DISPOSITIVO. DANGER A fully-populated Brocade MLX Series-4, -8, or -16 chassis is heavy. TWO OR MORE PEOPLE ARE REQUIRED WHEN LIFTING, HANDLING, OR MOUNTING THESE DEVICES.
Page 323 Utilice un elevador mecánico para levantar el chasis. Hacen falta cuatro personas o más para colocar el chasis no poblado en el interior del armazón. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 324 Dangers DANGER Do not attempt to lift a Brocade MLX Series-32 chassis. It is extremely heavy. REMOVE THE POWER SUPPLIES AND INTERFACE MODULES FIRST (management, switch fabric, and all line cards). Use a mechanical lifting device to lift the chassis. Four or more people are required to position the unpopulated chassis into the rack.
Page 325 (puertos Tipo 2 o Tipo 4, según lo descrito en GR-1089-CORE, Número 5) y deben aislarse del cableado de la OSP expuesto. La incorporación de Protectores Primarios no proporciona protección suficiente para conectar dichas interfaces metálicamente al sistema eléctrico de la OSP. Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...
Page 326 Dangers Brocade MLX Series and Brocade NetIron XMR Installation Guide 53-1004195-02...

This manual is also suitable for:

Netiron xmr series Mlx-4 Mlx-8 Mlx-16 Mlx-32 Netiron xmr 4000 ... Show all

Brocade Communications Systems MLX Series Installation Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Brocade Communications Systems MLX Series

Summary of Contents for Brocade Communications Systems MLX Series
