90 | DR 100s | Basic Workflow

Checking the exposure settings

1. Check if the DR Detector Switch displays the name of the DR Detector
that's being used
a) If a wrong DR Detector is displayed, select the right DR Detector by
2. On a DR Detector that has a status indicator, check if the status of the DR
Detector is ready for exposure. If the status is not ready for exposure, the
DR Detector cannot be used for making an exposure.
3. Check if the exposure settings are suitable for the exposure.
The exposure settings are displayed on the software console and on the
tube head display.
a) If other exposure values are required than those defined in the NX
4. Check if the status of the X-ray modality is ready for exposure.
This indicates that the wireless DR Detector and the X-ray generator are
ready for making an exposure.
Related Links
Led beacon light
DR detector switch
0411D EN 20220627 1040
clicking the drop down arrow on the DR Detector Switch.
exam, use the console to overwrite the default defined exposure
settings.
WARNING:
Check if the led beacon light lights up green.
on page 40
on page 33
