Maximum radiation leakage
Figure 73: Heating and cooling curves
Table 43: X-ray tube
Model
Rotation speed
Nominal High voltage
Nominal focus dim. (IEC 60336)
Nominal anodic power (IEC 60613)
Anodic material
Anodic diameter
Anodic angle
Thermal capacity of the anode
Max continuous anode dissipation
Min. inherent filtration (IEC 522)
Tube material
DR 100s | Product Information | 185
1 mGy/h
X22
3000 min‾¹
130 kVp
0.6 mm small focus
1.3 mm large focus
11 kW small focus
32 kW large focus
RTM
64 mm (2.52 inch)
15°
80 kJ (107 kHU)
300 W
0.7 mm Al eq.
glass
