164 | DR 100s | Product Information
Connecting DR 100s to a wired network
To connect DR 100s to a wired network:
1. Place the unit in secured position.
2. Connect a network cable to the connector for the hospital network and
plug it into a network socket.
Figure 69: Wired network connector
Related Links
Connectors for the hospital network, DR detectors and accessories
0411D EN 20220627 1040
on page 45
