Figure 25: Interfaces for registering the DR detector or connecting to the
network
Table 8: Interfaces for registering the DR detector or connecting to the
network
USB connector.
(1)
Network connector to connect the Registration Cable for
registering a DR Detector.
(2)
Network connector to connect the NX workstation to the
hospital network.
(3)
IR Data Communication Unit (optional).
(4)
Emergency stop button.
(5)
