172 | DR 100s | Product Information
Dimensions (in secured position)
width x length x height
Handle height
(adjustable by service)
Weight
Focus-floor distance (Z-axis)
Maximum height
Telescopic arm extension range
Rotation of the X-ray tube assembly
around the arm axis (α swivel)
Rotation of the X-ray tube assembly
around the column axis (β swivel)
Rotation of the X-ray tube assembly
around its axis (γ swivel)
Movement
Movement speed
Slope of the floor while driving
Slope of the floor while parking
(brakes must not be released)
Height of surmountable obstacles
Wheels diameter
0411D EN 20220627 1040
576 x 1290 x 1364 mm
940 - 960 mm
470 kg
(without DR detector)
675 mm - 2051 mm
2185 mm
360 mm
front: 750 - 1110 mm
lateral: 586 - 946 mm
± 90°
± 320° from secured position
110° (+90° ahead, -20° back)
motorized
The speed is proportional to the force
impressed on the transport handle.
forward, in secured position: 0 - 1.4
m/s
forward, in working position: 0 - 0.7
m/s
backward: 0 - 0.7 m/s
maximum 10° (18%)
maximum 10° (18%)
maximum 40 mm
front: 125 mm (damped)
rear: 300 mm
