INSTALLING THE FUSELAGE SERVOS

Because the size of servos difer, you
may need to adjust the size of the precut
opening in the mount. he notch in the
sides of the mount allow the servo lead to
pass through.
Install the rubber grommets and brass
collets into all servos. Test it the servos
into the fuselage servo mounts.
Secure the servos with the screws pro-
vided with your radio system.
1.
Elevator servo
Rudder servo
THROTTLE SERVO ARM
INSTALLATION
Install adjustable servo connector in the
servo arm as same as picture below:
1.
.
.
hrottle servo
