Removing the Front Panel

Removing the Front Panel
1. Power down your workstation as described in "Getting Started." If
2. Once the door is open, unscrew the two panel-detach screws in the top
3. Swing the entire front panel 45
4. Pull the panel straight out to remove it (Step 4 in the figure below).
Figure 2-1 Removing the Front Panel
14
locked, unlock the door on the front of the system and swing it to the
right (see Step 1 in the figure below).
and bottom corners of the right edge of the panel. These screws are
visible when the door is open (Step 2 in the figure below).
below).
Set the panel and its screws aside.
4
3
4
o o
to 90 to the left (Step 3 in the figure
2
