Removing the Memory Card(s) (DIMMs)

1. Press downward on the ejector tabs located on each side of the
Figure 2-6 Removing a DIMM
Ejector Tab
2. Grasp the memory card by its edges and lift it straight out. Place the
3. Refer to the label inside the system for reference.
4. Repeat steps 1 and 2 for all memory cards.
Chapter 2
memory card (DIMM) slot.
card on the conductive sheeting.
System Board Removal/Replacement
Removing the Memory Card(s) (DIMMs)
Ejector Tab
19
