Preparing Your Workstation - HP Visualize J5000 Upgrade Instructions

Getting Started

Preparing Your Workstation

Preparing Your Workstation
The workstation must be running HP-UX 10.20 with Additional Core
Enhancements (ACE4) 9906 or later to accommodate the PA8600
upgrade. It should report B.10.20. If the workstation is running an older
version of HP-UX, update the operating system software before
continuing. Use the command /usr/sbin/swlist -l bundle | grep ACE to
view what software products are loaded in your system. If the product
list includes B6193DA, you do not need to update HP-UX.
1. Determine the workstation's LAN ID by entering the following
command: /usr/sbin/lanscan.
The output is similar to the following:
Hardware Station
Path Address
2.0.2 0x08000970ECC0 0 UP
Record the LAN ID here. You will need it after installing the new
system board:
Enter LAN ID: ___ ___ ___ ___ ___ ___ -___ ___ ___ ___ ___ ___
You must supply the dash (-) between the first six digits and the last
six digits
After you install the new system board and power on the system for
the first time, you may be prompted for the LAN ID.
2. Power down the system as described in the next section.
10
Crd Hardware Net-Interface NM MAC HP DLPI Mjr
In# State NameUnit State ID Type Support Num
lan0 UP 4 ETHER YES
